Factory Direct 8 2 1 Ethernet switch 4ch 8ch 16ch 24ch 10/100/1000 Base T Gigabit switch AC power PoE switch
- Category: >>>
- Supplier: Shenzhen Opmedia Technology Co. Ltd.
Share on (1601001860742):
Product Overview
Description
1， Gigabit Ports：This ethernet switch includes 8 gigabit PoE ports, 2 Gigabit uplink, 1G SFP port, support 1000Mbps POE and uplink connection, excellent data transmission performance. The SFP port suitable for longer distance transmission than Ethernet.
2，120W High PoE+ Power：This poe switch built-in industrial power supply, no external power adapter, easier to install. The whole power is 120W, each port up to 30W, POE output power is more stable. Please note: not compatible 24V passive PoE
3，Plug and Play：The PoE ports 1-8 support VLAN isolation, the traffic are isolated from each other, can only communicate with the uplink 9-11 to reduce network congestion. Plug and Play, just plug in the power cord and network cable, no configuration required,easy to use.
4，AI WatchDog, Qos：Support watchdog AI intelligent detection. When the POE device fails or crashes and goes offline, it will automatically restart the device to restore the link, make operation and maintenance more easier. Ports 1 and 2 support QoS, when a lot of network data causes congestion, the data of these 2 ports will be forwarded first, to ensure that the data of important devices will not be lost.
,5，Wide Applications：PoE and non-POE devices can be connected to this poe hub, such as poe camera/wireless ap, switch, router, computer, etc. It runs without noise and can be installed in office, home, and commercial locations, it is the good choice for high bandwidth requirements
2，120W High PoE+ Power：This poe switch built-in industrial power supply, no external power adapter, easier to install. The whole power is 120W, each port up to 30W, POE output power is more stable. Please note: not compatible 24V passive PoE
3，Plug and Play：The PoE ports 1-8 support VLAN isolation, the traffic are isolated from each other, can only communicate with the uplink 9-11 to reduce network congestion. Plug and Play, just plug in the power cord and network cable, no configuration required,easy to use.
4，AI WatchDog, Qos：Support watchdog AI intelligent detection. When the POE device fails or crashes and goes offline, it will automatically restart the device to restore the link, make operation and maintenance more easier. Ports 1 and 2 support QoS, when a lot of network data causes congestion, the data of these 2 ports will be forwarded first, to ensure that the data of important devices will not be lost.
,5，Wide Applications：PoE and non-POE devices can be connected to this poe hub, such as poe camera/wireless ap, switch, router, computer, etc. It runs without noise and can be installed in office, home, and commercial locations, it is the good choice for high bandwidth requirements
Network Standard | IEEE 802.3,IEEE 802.3u,IEEE 802.3x, IEEE 802.ab, IEEE 802.AF/AT |
Port | 8*10/100/1000Mbps RJ45 port 2*10/100/1000Mbps RJ45 uplink port 1*1000Mbps SFP uplink port |
Function | POE |
POE power | 8*10/100/1000Mbps RJ45 port support POE+ The whole power max. is120W Each port max. power supply reached 30W |
Model Number | S310-F0821GP |
POE Connection | 1-8 port support IEEE802.3af/at Both1/2+,3/6- and 4/5+,7/8- End-span |
Performance | Store and forward MAC address table 4k Switching capacity16Gbps |
Forwarding Rate | 10BASE-T:14880PPS/port 100BASE-tx:148800pps/port 1000BASE-tx:1488000pps/port |
Environment | Operating Temperature:-10℃ - -55℃ |
Forwarding rate | Power priority mechanism, fast and forward, MAC automatic learning and aging IEEE802.3X Full-duplex and backpressure for half-duplex mode |
Power | Built in power base board Input:220V,50HZ,Output:DC52V±5% 2.3A≤120W |
Weight &Size | 1KG 200mm×118mm×44mm(L×W×H) |
Company Profile
Shenzhen Opmedia Technology Co., Ltd., Ltd. was founded in 2012, headquartered in Guangming District, Shenzhen. It is a high-tech enterprise committed to the research and development, production, sales and service of optical fiber communication and network communication equipment, and is a market innovator and application technology pioneer in the field of global optical communication and optical network interconnection. The company has a strong, professional communication technology research and development team, over the years in the field of optical fiber communication for many years, after more than 10 years of operation, has successfully opened up the international market, products have been widely used and recognized by customers around the world, won a good reputation. We are committed to providing customers with quality products and good service..
Our Advantage
R&D advantage
Product advantages
With more than 30 experienced optical module engineers, we also provide training courses for foreign engineers and
communicate with foreign senior engineers to maintain our leading position in R & D. As over 10 years customized optical modules provider, keeping learn and exploring are our faith.
communicate with foreign senior engineers to maintain our leading position in R & D. As over 10 years customized optical modules provider, keeping learn and exploring are our faith.
Product advantages
Strict quality management, non-performing rate control in less than five over ten thousand, the production of
each steps have inspection. Full-range product lines reflected in different package types、data-rate and compatible brands. And we also provide customized products to meet the needs of different industries personalized demand.
Cost advantage
each steps have inspection. Full-range product lines reflected in different package types、data-rate and compatible brands. And we also provide customized products to meet the needs of different industries personalized demand.
Cost advantage
We strictly control the quality of raw materials, most of the raw materials purchase from Japan and USA. Long-term
stable raw material suppliers give us good price support and we also achieve scale economies production. Low mobility of employees by training and humanized management reduce the cost of staff mobility problems.
stable raw material suppliers give us good price support and we also achieve scale economies production. Low mobility of employees by training and humanized management reduce the cost of staff mobility problems.
Manufacturing Technique
SMT Production
AOI checking
DIP
PCBA inspection
Assembly
Aging
FAQ
Q: Can I use supplies of differing voltage as the redundant power ? For example, 12v and 24v without unwanted effects or damage?
A: Yes, you can use supplies of differing voltages. There will be no ill effects, the switch's internal regulators were designed
to handle a wide range of voltage inputs.
to handle a wide range of voltage inputs.
Q: What temperature range can this device handle?
A: The operating temperature is -40～85℃（-40～185°F）
Q: Does it come with a small din rail?
A: The switch support 35mm din rail ,but the din rail is not included.
A: The switch support 35mm din rail ,but the din rail is not included.
Q: Does this have any management capability?
A: No,This is a unmanaged industrial ethernet switch.
Q: Is this unit fanless?
A: Yes, the unit is fanless. No noise.
