New high qualy it Dell server r740 Intel Xeon R740 2U/2 6230R 24 x 2.5 H740p 16 x 2.4TB 10k SAS 5720 1600W*2 poweredge r740

Model

Dell EMC PowerEdge R740

Processor Name

Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor

Memory

• 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s
• Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max
• Supports registered ECC DDR4 DIMMs only

Storage controllers

• Internal controllers: PERC H745, HBA355I, S150, H345, H755, H755N
• Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB
• Boot Optimized Storage Subsystem (BOSS-S1) HW RAID 2 x M.2 SSDs 240 GB or 480 GB
• External PERC (RAID): PERC H840, HBA355E

Drive Bays

Front bays:
• Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB • Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB
• Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB
• Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.84 TB Rear bays:
• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB
• Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB

Power Supplies

• 800 W Platinum AC/240 mixed mode
• 1100 W Titanium AC/240 mixed mode
• 1400 W Platinum AC/240 mixed mode
• 2400 W Platinum AC/240 mixed mode

Dimensions

• Height – 86.8 mm (3.41 inches)
• Width – 482 mm (18.97 inches)
• Depth – 758.3 mm (29.85 inches) - without bezel 772.14 mm (30.39 inches) - with bezel

GPU support

Up to two double-width 300 W, or four single-width 150 W, or six single-width 75 W accelerators

PCIe

Up to 8 x PCIe Gen4 slots (up to 6 x16) with support for SNAP I/O modules

Operating System and Hypervisors

• Canonical Ubuntu Server LTS
• Citrix Hypervisor
• Microsoft Windows Server with Hyper-V
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
• VMware ESXi
