Low Voltage Linear Actuator Motor Hitbot Z Mod KK60 Mini Electric Linear Robots Guides Synchronized Controller

Share on (1601002311530):


Price:US$ 456.00 - US$ 686.00

Quantity:


Product Overview

Description



Product Description






Specification


Item
Value
Model Number
Z-Mod-KK-60 (Length Customized)
Core Components
Motor
Place of Origin
China
Brand Name
HITBOT
Electric Motor
100W/DC24V
Rated Acceleration
0.3G
The Max Speed
500 (mm/sec)
Stroke Range
58-508 mm (100 interval)
Repeatability
±0.02mm
Driving Mode
Ballscrew 12mm turn to C7 grade
Sensor
-LS,HOME,+LS ,NPN, 24V DC
Base Material
Cast Steel,Black Color
Precise requirement of installation area
Evenness, below 0.05mm
Working Environment
0-4℃,85%RH(No Frost)


Applications










Company Profile






Established in 2015, HITBOT is 5-year experienced collaborative robot manufacturer, mainly specializing in designing and producing light-weight table-top collaborative robot and electric robot grippers.

With over 10 years of technology research and development, HITBOT has successfully lowered the threshold of automation transformation for small and medium-sized enterprises from the dimensions of cost and applicability. HITBOT has got over 50 patents and utilized them to optimized the machine performance and user experience, such as the easiest way of programming by graphic teaching, APP teaching, drag teaching.

HITBOT has a production facility of over 10,000 square meters, achieving an annual output of 20,000 pieces. Starting overseas business in 2018, HITBOT cobots and grippers have all been certificated with CE and FC, and sold to over 20 countries such as the US, CA, JP, SG, UK, DE, and etc.

In the future, HITBOT will continue dedicating efforts in cobot innovation to promote realizing the transformation of Industry4.0 for small and medium-sized enterprises.


Contact




FAQ


1. Who are we?
We are based in Guangdong, China, start from 2015,sell to Eastern Asia(60.00%),Domestic Market(20.00%),Western Europe(10.00%),North America(10.00%). There are total about 51-100 people in our office.

2. How can we guarantee quality?
Always a pre-production sample before mass production
Always final Inspection before shipment

3.What can you buy from us?
Robot arm,Robot gripper,Robot manipulator,Linear actuator,Industrial robot

4. Why should you buy from us not from other suppliers?
Established in 2015, HITBOT is 5-year experienced collaborative robot manufacturer, mainly specializing in designing and producing light-weight table-top collaborative robot and electric robot grippers.

5. What services can we provide?
Accepted Delivery Terms: FOB
Accepted Payment Currency:USD,EUR,CNY
Accepted Payment Type: T/T,PayPal
Language Spoken:English,Chinese
