Electronic silicone electrical squishy gel soft liquid silicone for rimuovere il gel di silicone per pcb
- Category: >>>
- Supplier: Shenzhen Haneste New Material co. LTD
Share on (1601002464727):
Product Overview
Description
Product Description
HN-6607A/B silicone gel
Product Description :This product is a very soft, low cross-linking density addition silicone rubber. It is a low viscosity liquid before vulcanization. After vulcanization, in addition to the general characteristics of addition silicone rubber, it has good shock absorption, moisture resistance and sealing due to its soft nature. properties and excellent dielectric insulation properties over
a wide range of temperature and humidity.
Product Features:
1. Medium temperature curing, the curing time can be adjusted according to different temperatures;
2. It is low-viscosity silicone oil before curing and gel elastomer after curing.
Instructions：
1. Before mixing, component A needs to be properly stirred manually or mechanically, and component B should be fully shaken in a sealed state before use.
2. When it needs to be attached to the application material, please confirm whether it can be attached before use, and then apply it.
2. When it needs to be attached to the application material, please confirm whether it can be attached before use, and then apply it.
3. Before construction, please weigh and mix according to the weight ratio of A:B = 1:1, and stir thoroughly before applying glue.
Packing and shipping :
This product is 40KG per group;
Component A is 20KG (in barrels), and Component B is 20KG (in barrels)
Storage and transportation:
1. Store in a cool and dry place. The storage period is 6 months (at 25℃).
2. Products that have exceeded the shelf life should be confirmed for any abnormalities before use.
3. Components A and B of the colloid must be sealed and stored, and be careful of leakage during transportation!
4. Such products are non-dangerous goods and can be transported as general chemicals.
*Parameters are for reference only, the above product performance can be adjusted according to customer requirements.
Component A is 20KG (in barrels), and Component B is 20KG (in barrels)
Storage and transportation:
1. Store in a cool and dry place. The storage period is 6 months (at 25℃).
2. Products that have exceeded the shelf life should be confirmed for any abnormalities before use.
3. Components A and B of the colloid must be sealed and stored, and be careful of leakage during transportation!
4. Such products are non-dangerous goods and can be transported as general chemicals.
*Parameters are for reference only, the above product performance can be adjusted according to customer requirements.
Specification
Model | Color | Viscosity (mPa.s) | Hardness (Shore A) | Tensile strength (Mpa) | Tear Strength(kN/m) | Elongation(%) | Mixing ratio A:B | Operation time (h) | Curing time (h) |
E600# | translucent | 800 | 0 ±2 | 2 | 4 ±2 | 450 | 1:1 | 0.5 | 4 |
E605# | translucent | 2000 | 5 ±2 | 3 | 12±2 | 500 | 1:1 | 0.5 | 4 |
E610# | translucent | 2500 | 10±2 | 4.8 | 13±2 | 550 | 1:1 | 0.5 | 4 |
E615# | translucent | 3500 | 15±2 | 5.1 | 16±2 | 470 | 1:1 | 0.5 | 4 |
E620# | translucent | 5000 | 20±2 | 5.3 | 23±2 | 520 | 1:1 | 0.5 | 4 |
E625# | translucent | 6000 | 25±2 | 5.5 | 26±2 | 450 | 1:1 | 0.5 | 4 |
E630# | translucent | 7500 | 30±2 | 6.5 | 18±2 | 410 | 1:1 | 0.5 | 4 |
E635# | translucent | 8500 | 35±2 | 7 | 18±2 | 380 | 1:1 | 0.5 | 4 |
E640# | translucent | 11000 | 40±2 | 7.2 | 19±2 | 330 | 1:1 | 0.5 | 4 |
E645# | translucent | 14000 | 45±2 | 8.2 | 16±2 | 320 | 1:1 | 0.5 | 4 |
E650# | translucent | 15000 | 50±2 | 7.5 | 13±2 | 240 | 1:1 | 0.5 | 4 |
E655# | translucent | 18000 | 55±2 | 5.8 | 12±2 | 150 | 1:1 | 0.5 | 4 |
E660# | translucent | 20000 | 60±2 | 5.8 | 11±2 | 130 | 1:1 | 0.5 | 4 |
