High power 100A power supply soft start board circuit board high current relay suitable for Class A power amplifier
- Category: >>>
- Supplier: Shenzhen TCT Electronics Co. Ltd.
Share on (1601002529968):
Product Overview
Description
Product Description
Specification
item | value |
Private Mold | NO |
Brand Name | TCT Electronics |
Model Number | High power 100A power supply soft start board |
Type | Professional Amplifier |
Channels | Independent three channel |
Place of Origin | China |
Guangdong | |
Product Name | amplifier board |
Keyword | 1 |
Application | car audio |
Function | Large Capacity Switching Power Amplifier |
Color | blue |
Feature | Super Bass Stereo Sound |
MOQ | 30 Pcs |
Chip | original |
Weight | 70g |
leadtime | 1-7days |
Packing & Delivery
High power 100A power supply soft start board, circuit board, high current relay suitable for Class A power amplifier without soldering
Product features:
The function of the soft start board is to reduce the instantaneous surge current during startup, in order to reduce the impact of the machine on the power grid and extend the lifespan of the switch. This board uses a high current (100A) pure copper foot relay and a large thermistor NTC 20D-20 to effectively protect the machine and prevent excessive startup current.
The product does not require an auxiliary power supply, only 2 wiring terminals, one connected to the power input (previously connected to a switch control), and one output connected to the load, making it very convenient to use.
Working principle:
In the early stage of connecting the power supply, the load is powered by a thermistor with a negative temperature coefficient. As the temperature of the thermistor increases, the resistance decreases and the voltage slowly rises, effectively suppressing the impact of surge current on the line and other electrical appliances. After about 2 seconds, the relay will close and short-circuit the thermistor. The power will be directly supplied to the load through the relay contacts, and the load will enter normal working state.
Product parameters:
Name: High power soft start circuit board
RGL high-power and high current 100A pure copper foot relay relay:
Size: 67mm * 61mm * 30mm (height), hole spacing: 58 * 53mm, small volume
Power supply voltage adaptation range: AC 150V to 280V.
Weight: 70g
Wiring sequence: Power - Switch - Soft Start - Transformer
Applicable scope:
Suitable for high-end audio power input or other high startup current machine applications. The suitable power for use is within 2200W. Long term load should be within 1200W. This product is not suitable for motor use.
Product features:
The function of the soft start board is to reduce the instantaneous surge current during startup, in order to reduce the impact of the machine on the power grid and extend the lifespan of the switch. This board uses a high current (100A) pure copper foot relay and a large thermistor NTC 20D-20 to effectively protect the machine and prevent excessive startup current.
The product does not require an auxiliary power supply, only 2 wiring terminals, one connected to the power input (previously connected to a switch control), and one output connected to the load, making it very convenient to use.
Working principle:
In the early stage of connecting the power supply, the load is powered by a thermistor with a negative temperature coefficient. As the temperature of the thermistor increases, the resistance decreases and the voltage slowly rises, effectively suppressing the impact of surge current on the line and other electrical appliances. After about 2 seconds, the relay will close and short-circuit the thermistor. The power will be directly supplied to the load through the relay contacts, and the load will enter normal working state.
Product parameters:
Name: High power soft start circuit board
RGL high-power and high current 100A pure copper foot relay relay:
Size: 67mm * 61mm * 30mm (height), hole spacing: 58 * 53mm, small volume
Power supply voltage adaptation range: AC 150V to 280V.
Weight: 70g
Wiring sequence: Power - Switch - Soft Start - Transformer
Applicable scope:
Suitable for high-end audio power input or other high startup current machine applications. The suitable power for use is within 2200W. Long term load should be within 1200W. This product is not suitable for motor use.
