outdoor industry electric sweeper green machine vacuum brooms sweeping car truck

Component Name

Serial Number

project

Parameter values/specifications

Complete vehicle

1

Model

YX-G25

2

Sweeping width

2500mm

3

Main brush width

800mm

4

working efficiency

20000-35000m²/h

5

working hours

3-8h

6

Dustbin capacity

220L

7

Side-brush diameter

Front 700mm  Middle 600mm

8

Walking speed

0-14km/h

9

Overall dimensions

3500*2500*2730mm

10

water tank

300L

11

Vacuum filtration area

12m²

12

Tyre type

Front 400-10, rear 400-10 solid tyre

13

control mode

Intelligent control system (timed dust shaking function)

Warning

lights

1

Headlight

Four way LED headlights

2

tail light

Steering+braking+driving integrated taillights

3

Alarm lamp

Top operation warning light

4

HD reverse camera

Storage

battery

1

Type

Lead acid maintenance free (optional with lithium battery)

2

Battery capacity

Standard 48V-150AH*6/200AH*8/240AH*8 lead-acid battery

Electrical machinery

1

Walking motor

2200W intelligent gear change

2

Rolling brush motor

1000W

3

side-brush motor

4*100W

4

Motor voltage

48V

High pressure water pump

1

High pressure fog-cannon range

6-10m

2

High pressure water-gun range

10-18m

3

power

1500W

4

Pressure range

0-13Mpa

5

Max rate of flow

11L/min

Rearview

mirror

1

model

Dedicated for sweeping vehicles

Note: Standard  double-fan.optional with four-fan.

Machine performance: The combination of suction, sweeping, and spraying effectively suppresses dust and thoroughly cleans ground waste and dust.

Place of use: Used for cleaning workshop, parks, streets, lanes, docks, property communities, warehouses, sports venues, schools, airports, and other areas in the factory area. The cleaning efficiency is 10 times that of the traditional manual cleaning, and one sweeper can replace 8-12 Cleaner.
