Hydraulic 10 Ton 3 Jaw Gear Puller has the advantage of compact structure and working agility
- Category: >>>
- Supplier: Bazhou Dpair Hardware Equipment Co. Ltd.
Share on (1601003459799):
Product Overview
Description
Products Description
manual hydraulic bearing puller
Manual hydraulic bearing puller is a kind of ideal tool compared with traditional pullers. It owns compact structure and flexible application. The puller is easy to carry and operate and seldom be restricted by surroundings. This hydraulic gear puller owns powerful capacity of 15T with 3-jaw 4-hook design. 2 or 3 jaws can be exchanged freely for different usages. Safety flooding valve avoids overloading, centralized positioning device included. Work Pattern: Move the handle while operation, piston actuating lever moves forward smoothly and steadily under the effect of oil pressure. Jaws move backward relatively to pull things out.
It integrates pump, tubing and plotter. Its forged steel double-shoulder bearings can pull two or three legs, and three jaws can be adjusted. The pump head is very flexible and can rotate 360°. The integrated molding can effectively prevent oil leakage and cracking.
This gear puller can be used vertically and horizontally, which can fully meet various work requirements. The alloy steel jaws can be firmly fixed at the position that needs to be worked, not easy to slide.
Made of high-quality carbon steel, making it strong, corrosion resistant, and rust resistant. The jaws are forged with alloy steel, the pump body is forged with high-carbon steel, and the shell is electroplated, which will provide you with stable performance and maximum durability.
Wide range of applications, suitable for railway vehicle maintenance, mechanical installation, mine maintenance, construction engineering support etc. It can also disassemble round work pieces such as pulleys, gears and bearings in various mechanical equipment.
feature:
1.Durable material: the hydraulic gear puller is made of heavy-duty forged steel, featuring superior strength and no oil leakage.
2.Adjustable jaws: you can install 2 or 3 jaws and adjust the height as needed besides, the pump head of the hydraulic bearing puller can rotate 360°, which is easy for you to operate and use the tool
3.Bidirectional operation: the hydraulic gear puller can be operated horizontally or vertically without site restriction.
4.Humanized design: equipped with a safety relief valve, the piston rod, the detachable ejector pin and the movable handle, the hydraulic steering wheel puller has the advantage of compact structure and working agility 3-jaw structure has the same load distribution, which can be securely clamped and concentrically pulled the 3-jaw gear puller evenly distributes the tension and protects the gear
5.Diverse scenario: a hydraulic puller set is an ideal tool for pulling hubs, flanges, gears, pulleys, flywheels, bearings chucks from shafts it is widely suitable for car maintenance factories, mechanical factories and repair workshops, etc.
Manual hydraulic bearing puller is a kind of ideal tool compared with traditional pullers. It owns compact structure and flexible application. The puller is easy to carry and operate and seldom be restricted by surroundings. This hydraulic gear puller owns powerful capacity of 15T with 3-jaw 4-hook design. 2 or 3 jaws can be exchanged freely for different usages. Safety flooding valve avoids overloading, centralized positioning device included. Work Pattern: Move the handle while operation, piston actuating lever moves forward smoothly and steadily under the effect of oil pressure. Jaws move backward relatively to pull things out.
It integrates pump, tubing and plotter. Its forged steel double-shoulder bearings can pull two or three legs, and three jaws can be adjusted. The pump head is very flexible and can rotate 360°. The integrated molding can effectively prevent oil leakage and cracking.
This gear puller can be used vertically and horizontally, which can fully meet various work requirements. The alloy steel jaws can be firmly fixed at the position that needs to be worked, not easy to slide.
Made of high-quality carbon steel, making it strong, corrosion resistant, and rust resistant. The jaws are forged with alloy steel, the pump body is forged with high-carbon steel, and the shell is electroplated, which will provide you with stable performance and maximum durability.
Wide range of applications, suitable for railway vehicle maintenance, mechanical installation, mine maintenance, construction engineering support etc. It can also disassemble round work pieces such as pulleys, gears and bearings in various mechanical equipment.
feature:
1.Durable material: the hydraulic gear puller is made of heavy-duty forged steel, featuring superior strength and no oil leakage.
2.Adjustable jaws: you can install 2 or 3 jaws and adjust the height as needed besides, the pump head of the hydraulic bearing puller can rotate 360°, which is easy for you to operate and use the tool
3.Bidirectional operation: the hydraulic gear puller can be operated horizontally or vertically without site restriction.
4.Humanized design: equipped with a safety relief valve, the piston rod, the detachable ejector pin and the movable handle, the hydraulic steering wheel puller has the advantage of compact structure and working agility 3-jaw structure has the same load distribution, which can be securely clamped and concentrically pulled the 3-jaw gear puller evenly distributes the tension and protects the gear
5.Diverse scenario: a hydraulic puller set is an ideal tool for pulling hubs, flanges, gears, pulleys, flywheels, bearings chucks from shafts it is widely suitable for car maintenance factories, mechanical factories and repair workshops, etc.
model | SDY-1 | SDY-5 | SDY-10 | SDY-15 | SDY-20 | SDY-25 |
Maximum horizontal draw distance | 200 | 250 | 300 | 350 | 400 | 450 |
Maximum longitudinal draw distance | 140 | 160 | 180 | 200 | 200 | 200 |
Axis travel | 50 | 50 | 50 | 50 | 50 | 60 |
tip length | 22 | 23 | 24 | 24 | 24 | 24 |
Thread diameter | 45.6 | 60 | 60 | 73 | 88 | 110 |
diameter | 59 | 75 | 75 | 88 | 102 | 109 |
weight | 6.5KG | 10.5KG | 12KG | 16KG | 25KG | 33KG |
total length | 360 | 375 | 375 | 400 | 460 | 470 |
long handle | 390 | 390 | 390 | 390 | 390 | 390 |
Claws and feet long | 240 | 300 | 300 | 300 | 400 | 500 |
BAZHOU DPAIR HARDWARE EQUIPMENT CO., LTD. is a specialized manufacturer of hydraulic crimping tools,Our company has won ISO9001, CE certificate and other local certificates,as well as "National High-tech Enterprise" and "Excellent and Innovative Enterprise
Bazhou Depaier Hardware Machinery Co., Ltd. was established in 2010. The company is a high-tech enterprise in Hebei Province. It is located in Bazhou City, Hebei Province, 90 kilometers away from Beijing. It covers an area of 18,000 square meters and has more than 210 employees. The company integrates R&D, production and sales of electric power engineering machinery and has an engineering machinery R&D laboratory. The company has been engaged in overseas sales since its establishment. Now its products are sold to more than 90 countries and have agents in Australia, Russia, Dubai, Saudi Arabia, India and other places. After years of continuous efforts, the power engineering machinery produced by our company has now reached the leading domestic level, contributing to accelerating the country's mechanization construction. We have advanced production technology and production equipment and can develop or customize products for customers according to their needs. Sincerely look forward to every customer or friend coming to our company to visit or negotiate business! I look forward to cooperating with you and extend my best wishes to you.
Bazhou Depaier Hardware Machinery Co., Ltd. was established in 2010. The company is a high-tech enterprise in Hebei Province. It is located in Bazhou City, Hebei Province, 90 kilometers away from Beijing. It covers an area of 18,000 square meters and has more than 210 employees. The company integrates R&D, production and sales of electric power engineering machinery and has an engineering machinery R&D laboratory. The company has been engaged in overseas sales since its establishment. Now its products are sold to more than 90 countries and have agents in Australia, Russia, Dubai, Saudi Arabia, India and other places. After years of continuous efforts, the power engineering machinery produced by our company has now reached the leading domestic level, contributing to accelerating the country's mechanization construction. We have advanced production technology and production equipment and can develop or customize products for customers according to their needs. Sincerely look forward to every customer or friend coming to our company to visit or negotiate business! I look forward to cooperating with you and extend my best wishes to you.
Product packaging
FAQ
1. Is it in stock? and how many days get it ?
Yes, can send out immediately if we have stock,
if not,will 7-15 days.
2. What is your MOQ ?
One set is MOQ,
Larger MOQ,and better price.
3. What the delivery time ?
All depend on the order quantity,usually bulk
For sample orders, we deliver within 7-15 days
For 3-15 sets, we will deliver in 10-25 days.
For orders of more than 15 units, we deliver in 15-40 days
By ocean 30-45days
4. What payment way you accept ?
Alipay, Paypal, TT,Western Union,MoneyGram
Yes, can send out immediately if we have stock,
if not,will 7-15 days.
2. What is your MOQ ?
One set is MOQ,
Larger MOQ,and better price.
3. What the delivery time ?
All depend on the order quantity,usually bulk
For sample orders, we deliver within 7-15 days
For 3-15 sets, we will deliver in 10-25 days.
For orders of more than 15 units, we deliver in 15-40 days
By ocean 30-45days
4. What payment way you accept ?
Alipay, Paypal, TT,Western Union,MoneyGram
Post-sales service
First of all, the probability of failure of our equipment is very low. According to the customer's feedback,
there will be no failure within 2 years under normal working conditions. Our company has professional translators, can communicate
with customers in multiple languages, in order to facilitate the installation and commissioning of products. When the equipment is
delivered, we will give enough worn parts to meet the future maintenance work and daily maintenance work If the equipment is
damaged within 2 years and needs to be repaired, we will send the required accessories by express delivery, which is free of
charge. If our engineers determine that the after-sales service must be on-site, our maintenance engineers will carry out on-site
maintenance services within 72 hours.
there will be no failure within 2 years under normal working conditions. Our company has professional translators, can communicate
with customers in multiple languages, in order to facilitate the installation and commissioning of products. When the equipment is
delivered, we will give enough worn parts to meet the future maintenance work and daily maintenance work If the equipment is
damaged within 2 years and needs to be repaired, we will send the required accessories by express delivery, which is free of
charge. If our engineers determine that the after-sales service must be on-site, our maintenance engineers will carry out on-site
maintenance services within 72 hours.
