6 Axis Collaborative Robot 10kg Payload Pick and Drop Robot with Onrobot Manufacturer Produced Robotic Gripper RG2
- Category: >>>
- Supplier: Shandong Chenxuan Robot Technology Co. Ltd.
Share on (1601003970427):
Product Overview
Description
Product Description
Product Introduction
6-axis vertical multi joint load: 180KG Action range: 2702mm Control cabinet: YRC1000 Purpose: handling, picking/packaging, palletizing, assembly/packaging
ER Series Flexible Cooperative Robot
SR Series Collaborative Robot
CR Series Flexible Cooperative Robot
Automatic Rotary Loading/Unloading Bin / Machine Tool Loading/Unloading Bin
Automatic Feed Pallet Bin / Palletizing Cooperative Bin / Automatic Loading And Unloading
Industrial Robot Bin / Automatic Circulation Chain Bin
Single axis horizontal servo positioner
Single axis main tail box type servo positioner
Spindle box type single axis servo positioner
Vertical flipping three-axis servo positioner
Horizontal rotary three-axis servo positioner
Transfer robot
Welding robot
Stamping machine
Cooperative Robot
Conveyor line
Positioner
Silo
Ground track
Specification
product details
Contribute to improving productivity through high-speed movements.
The allowable moment and inertia moment of the wrist axis can correspond to various types of work and fixtures
Reduced the number of cables between the robot and the control cabinet, improved maintenance while providing simple equipment
The allowable moment and inertia moment of the wrist axis can correspond to various types of work and fixtures
Reduced the number of cables between the robot and the control cabinet, improved maintenance while providing simple equipment
Standard specifications | MOTOMAN-GP180 | ||
model | YR-1-06VX180-A00 | ||
structure | Vertical multi joint type (6 degrees of freedom) | ||
Portable quality * 1 | Hand head | 180kg | |
On the U-arm | 30kg | ||
Maximum reachable | 2702 ㎜ | ||
Repetitive positioning accuracy * 2 | 0.05mm | ||
Action range | S-axis (rotation) | -180°-+180° | |
L-axis (lower arm) | -60°- +76 | ||
U-axis (upper arm) | -86*-+90° | ||
R-axis (wrist rotation) | 360*- +360* | ||
B-axis (wrist swing) | 16900 | ||
T-axis (wrist rotation) | 360*- +360 | ||
Maximum speed | S-axis (rotation) | 2.18rad/s，125°/s | |
L-axis (lower arm) | 2.01rad/s，115°/s | ||
U-axis (upper arm) | 2.18rad/s，125°/s | ||
R-axis (wrist rotation) | 3.18rad/s，182°/s | ||
B-axis (wrist swing) | 3.05rad/s，175/s | ||
T-axis (wrist rotation) | 4.63rad/s.265/s | ||
Allowable torque | R-axis (wrist rotation) | 1000N.m | |
B-axis (wrist swing) | 1000N.m | ||
T-axis (wrist rotation) | 618N.m | ||
Allowable moment of inertia (GD2/4) | R-axis (wrist rotation) | 90kg.m2 | |
B-axis (wrist swing) | 90kg.m2 | ||
T-axis (wrist rotation) | 46.3kg.m2 | ||
Body quality | 1020kg | ||
Protection level | Body: IP54, wrist shaft: IP67 | ||
Installation environment | temperature | 0° – +45° | |
humidity | 20% -80% RH (without condensation) | ||
shock | Below 4.9m/s2 (0.5G) | ||
other | No flammable or corrosive gases are allowed, and liquids should be kept away from electrical noise sources | ||
Power capacity * 3 | 5.0kVA | ||
Installation method * 4 | Floor mounted | ||
purpose | Handling, picking/packaging, palletizing, assembly/repackaging | ||
Remarks | *1: JIS B 8432 serves as the reference. *2: It records the range of motion of the self axis rather than the ground reference. *3: Depending on the purpose and action mode. (Note) This table is recorded in the SI unit system. | ||
