China Macro Factory OEM Condensing Gas Boilers for Customized Heating Solutions
- Category: >>>
- Supplier: Guangdong Macro Gas Appliance Co. Ltd.
Share on (1601005399790):
Product Overview
Description
Product Description
| Model | LL1PBD20-20B6A | LL1PBD26-26B6A | LL1PBD30-30B6A |
| Gas Type | NG | NG | NG |
| Max./Min. Heat Load Input Power(Kw) | 20/7.5 | 25.6/8.5 | 29.6/10.8 |
| Max./Min. Heat Loading Output Power(80~60℃)Kw | 19/7 | 24.6/7.8 | 28.5/10.2 |
| Max./Min. Heat Loading Output Power(50~30℃)Kw | 20/7.2 | 26/8.2 | 30/10.5 |
| DHW Max. Heat Load Input Power(Kw) | 20 | 25.6 | 29.6 |
| DHW Efficiency(%) | 96.23% | 96.72% | 97.02% |
| Heating Efficiency(%) | 101.68% | 104.68% | 105.13% |
| Rated Max./Min. Power(W) | 125/110 | 135/115 | 135/115 |
| Enclosure Protection Class | IPX4D | IPX4D | IPX4D |
| Net Weight(kg) | 36 | 37 | 40.5 |
| Product Dimension L*W*H | 720*420*312 | 720*420*312 | 720*420*335 |
| Package Dimension L*W*H | 830*515*420 | 830*515*420 | 830*515*443 |
