Model power | ZGD330 10-200KVA | |||||||||||||||||
Capacity | 10KVA | 15KVA | 20KVA | 30KVA | 40KVA | 60KVA | 80KVA | 100KVA | 160KVA | |||||||||
8KW | 12 KW | 16 KW | 24 KW | 32 KW | 48 KW | 64 KW | 80 KW | 128KW | ||||||||||
Input | ||||||||||||||||||
Rated voltage | 380/400/415 Vac three-phase | |||||||||||||||||
Voltage range | ±20% | |||||||||||||||||
Frequency range | 45-65Hz | |||||||||||||||||
Power factor | >0.92with harmonic filter | |||||||||||||||||
Current harmonic distortion | <5%with harmonic filter | |||||||||||||||||
Soft Start | 0-100% in10" | |||||||||||||||||
Bypass Input | ||||||||||||||||||
Rated voltage | 380/400/415Vac single-phase | |||||||||||||||||
Rated frequency | 50/60Hz | |||||||||||||||||
Standard features | Back Feed protection; split bypass line | |||||||||||||||||
Batteries | ||||||||||||||||||
Type | Maintenance-free lead-acid VRLA AGM / GEL;NICd | |||||||||||||||||
Battery voltage | 384VDC | |||||||||||||||||
AC ripple voltage | <1% | |||||||||||||||||
Inverter Output | ||||||||||||||||||
Number of phases | 3+N | |||||||||||||||||
Rated voltage(V) | 400Vac | |||||||||||||||||
Regulation of the output voltage | 380~424Vac phase/neutral(from control panel) | |||||||||||||||||
Frequency | 50/60Hz configurable | |||||||||||||||||
Overload | 110% 125% 150% of the rated current for 5h/10'/1' | |||||||||||||||||
Remote signaling | Volt free contacts | |||||||||||||||||
Remote controls | EPO and Bypass | |||||||||||||||||
Communication | RS232 + romote contacts | |||||||||||||||||
Relative humidity | <95% non condensing | |||||||||||||||||
