Price:$2,290.00 - $2,690.00

Quantity:


Product Overview

Description



FAQ


Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.










Products Description


 Item# CPS3200 3200mm Sliding Table Panel Saw with Scoring Balde
CHANSEN CPS3200 Panel Saw is dedicated designed and engineered for professional operations in job shops and small factories with affordable price. Like big industrial panel saws, CPS3200 is engineered with all necessary functionalities, including 315mm main blade, scoring blade, 3200mm sliding table, tilting arbors, dust hose between blade guard and dust port on cabinet, 1220mm solid rip fence, right-hand and rear extension boards. CPS3200 is available on output 2.5kw single phase motor or 3kw three phase motor.


Features


* Heavy-duty rugged steel frame
* 3200mm length sliding table
* Powerful 2.5kw/1ph or 3kw/3ph industrial motor
* Precision ground and coated worktable
* Dynamically balanced spindles perform at extreme low noise and vibration
* 1220mm rip cutting capacity
* Chromed and hardened solid rip fence rail
* Blade left tilting 45 degree
* Oversized 30mm spindle with 315mm main blade
* Standard scoring system for tear-free cutting
* Magnetic safety switch
* Outrigger table
* Cross cutting fence with extension
* Standard camlock hold down and trimming shoe
* User-friendly blade guard with dust hose
* CE approved


Optional Equipments
* Leitz 300mm/96T Premium sawblade



Details Images




Specification
Motor
220v/1ph/2.5kw, or 380v/3ph/3kw
Main casting table size
385mm x 800mm
Cast iron extension wing size
440mm x 800mm
Right extension board size
 440mm x 800mm
Rear extension board size:
310mm x 500mm
Sliding table size
3200mm x 270mm
Max. travel of sliding table
3200mm
Cross cut table size
 680mm x 580mm 0 - 45°, left
Cross cut fence capacity
1200 - 2200mm
Main spindle size
30mm
Main blade size
300mm
Main blade speed
4500RPM
Scoring blade size
90mm
Scoring spindle size
20mm
Scoring blade speed
8500RPM
Blade tilting
0 - 45°
Max. cut depth @ 90°
100mm
Max. cut depth @ 45°
80mm
Max. length to rip fence
1220mm
Max. cross cut length
3200mm
Max. cross cut width
1350mm
Dust port size
100mm
Machine weight
 335kgs
 Packing dimensions
1600 x756 x1050mm (Saw Body)
3260 x250 x320mm (Sliding Table)
Shipping weight
385kgs
