UPS manufacturer 3000va 2400w high frequency 127v 110v rack mount ups built in battery
- Category: >>>
- Supplier: Shenzhen Zhongguanda Technology Co. Ltd.
Share on (1601005796223):
Product Overview
Description
Specification
Model | C1KR | C1KRS | C2KR | C2KRS | C3KR | C3KRS | |||||
Phase | 1phase 2wire+PE | ||||||||||
Capacity | 1kVA/800W | 2KVA/1.6KW | 3KVA/2.4KW | ||||||||
Nominal Input Voltage | 220/230/240VAC | ||||||||||
Input Voltage Range | 90V~300V Halfload 176V~300V Full Load | ||||||||||
Input Frequency Range | 40~70Hz | ||||||||||
Input Power Factor | 0.99 @Full load | ||||||||||
Output Voltage | 230V（220/240/208V Selectable) | ||||||||||
Output Frequency (Sync.Mode) | 46Hz~54Hz; 57Hz~63Hz | ||||||||||
Output Frequency (Bat.Mode) | 50Hz+/-0.05Hz 60Hz+/-0.05Hz | ||||||||||
Output THDv% | 2% linear Load 6% Non-linear Load | ||||||||||
Output Waveform | Pure Sine wave | ||||||||||
Transfer Time | 0ms | ||||||||||
Battery Voltage/Capacity | 2 x 12V/7AH | 24V /36V external battery | 4 x 12V/7AH | 48V / 72V external battery | 4 x 12V/7AH | 72V/96V external battery | |||||
Max recharge current | 1.5A | 4A | 1.5A | 4A | 1.5A | 4A | |||||
Floating charge Votlage | 27.3V | 27.3V / 41.0V | 54.6V | 54.6V /81.8V | 81.8V | 81.8V/109.2V | |||||
Buzzer Alarm | Bat.Mode/Bat.Low/OverLoad/Fault | ||||||||||
Communication Port | RS232/ SNMP(option）/USB(option） | ||||||||||
Humidity | 5～97% (Non condensing) | ||||||||||
Operating Ambient temperature | 0~40℃ | ||||||||||
Product Description
Company Profile
Certificates:
Shenzhen ZGD Technology Co., Ltd. has imported high technique controlling facilities in our modern production line. We have successfully attained ISO9001 and CE certifications and comply with RoHS standard.
Application Fields:
Shenzhen ZGD Technology Co., Ltd. provides products and services in many countries around the world. Our products are extensively applied in fields of telecommunication, electric power, railway, finance, securities, hospital, school, aviation, airport, taxation, custom house as well as frontier defense, traffic, education, public security, national defense, energy sources and national key projects. They have won users' consentaneous compliments by complete varieties, reliable quality and perfect post-service.
Operation Principle:
No matter in what condition, we will put our customer at the first place, consider for customers and give them best service to meet their proper needs. We will firmly adhere to the enterprise culture of "uninterrupted power, uninterrupted progress". We will pay much attention to the quality of our products and try our best to make high-rank products.
Shenzhen ZGD Technology Co., Ltd. has imported high technique controlling facilities in our modern production line. We have successfully attained ISO9001 and CE certifications and comply with RoHS standard.
Application Fields:
Shenzhen ZGD Technology Co., Ltd. provides products and services in many countries around the world. Our products are extensively applied in fields of telecommunication, electric power, railway, finance, securities, hospital, school, aviation, airport, taxation, custom house as well as frontier defense, traffic, education, public security, national defense, energy sources and national key projects. They have won users' consentaneous compliments by complete varieties, reliable quality and perfect post-service.
Operation Principle:
No matter in what condition, we will put our customer at the first place, consider for customers and give them best service to meet their proper needs. We will firmly adhere to the enterprise culture of "uninterrupted power, uninterrupted progress". We will pay much attention to the quality of our products and try our best to make high-rank products.
