Product Overview

Description




hpe proliant dl380 gen10 24-core server Nas Server Storage Ssd Hp Server Rack hpe proliant dl380 serverserver dl380


Product Description

Product Description











Specification

Specification
























































































 Product specification and model





shape/height

shape/height









2U rack server



processor



processor











Up to 2 2nd Generation Intel® Xeon® Scalable Processors Platinum Series, up to 150W, up to 24 cores per CPU



Memory


memory








Up to 1TB of 2933MHz TruDDR4 (planned support) memory in 12 sockets with support for Intel® Optane™ DC persistent memory



hard disk



Drive bays (total/hot-plug)








24+6 SFF/12LFF+4+3 SFF+up to 2 SFF HDD/SSD hard disks, 20 NVMe PCIe SSDs and+m.2 expandable


Extensibility


Expansion slot










Standard configuration: 3 usable PCIe 3.0 slots, maximum 8 usable PCIe slots


network




NIC port












On board 4-port gigabit network adapter/network card Optional NC model does not include on board network controller 6 Optional
FlexibleLOM network adapter Optional network adapter based on standard PCIe slot



power supply



Power supply










Optional 500W/800W/1600W 1+1 hot plug redundant power supply, up to 96% titanium, hot plug redundant fan




Storage controller



Storage controller










Standard on-board array controller, supporting SATA RAID 0/1/10/5 optional HBA card based on special slot of array card,
supporting SATA/SAS RAID 0/1/10/5 optional Smart Array series array card based on special slot of array card, supporting SATA/SAS
RAID0/1/10/5/6/50/60/1 ADM optional HBA card based on standard PCIe slot and Smart Array array card supporting up to 4GB FBWC



management


System Management










XClarity Controller embedded management,
XClarity Administrator centralized infrastructure delivery,
XClarity Integrator plug-in and XClarity Energy Manager centralized server power management


operating system



Supported operating systems










Microsoft,Red Hat,VMware.


HBA/RAID support


HBA/RAID support










Hardware RAID (up to 24 ports) with flash cache;
up to 16 port HBAs


Serve



Limited Warranty










3-year 7 * 24 * 4 limited warranty service and installation service


Equipment size


44.54 x 67.94 x 8.73 cm (W x D x H, SFF models)
44.54 x 73.02 x 8.73 cm (W x D x H, LFF models)



Package size/  weight


weight: About 26 kg / size:97*59*27.5cm


Standard configuration 1:


DL388G10 , 1*4210R CPU,64G DDR4 Memory, 2*1.2TB SAS 10K HDD,750WPower Supply


Standard configuration 2:


DL388G10 , 2*4210R CPU,64G DDR4 Memory, 3*2.4TBSAS 10K HDD,2*750WPower Supply


Standard configuration 3:


DL380G10 , 2*5218R CPU,128G DDR4 Memory, 2*960G SSD  3*2.4TBSAS 10K HDD,2*750WPower Supply


Standard configuration 4:


DL380G10 , 2*5218R CPU,256G DDR4 Memory, 2*1.92T SATA SSD 3*2.4TBSAS 10K HDD,2*750WPower Supply


Custom configuration


Customize product configuration as required...
