CS6266C Heavy Duty lathe machine price Horizontal Turning Lathe Metal Manual Lathe
- Category: >>>
- Supplier: Tengzhou Hoton Machinery Co. Ltd.
Share on (1601006101028):
Product Overview
Description
WELCOME
GAP BED LATHE FEATURES:
Can perform internal and external turning, taper turning, end facing, and other rotary parts turning;
Threading Inch, Metric, Module and D.P.;
Perform drilling, boring and groove broaching;
Machine all kinds of flat stocks and those in irregular shapes;
Respectively with through-hole spindle bore, that can hold bar stocks in larger diameters;
Both Inch and Metric system are used on these series lathes, it's easy for people from different measuring
systems countries;
There are hand brake and foot brake for users to choose;
These series lathes operate on power supply of different voltages (220V,380V,420V) and different
frequencies (50Hz,60Hz).
SPECIFICATIONS | UNIT | CS6266C | ||
Capacity | Max. swing dia. over bed | mm | Φ660 | |
Max. swing dia.in gap | mm | Φ870 | ||
Max. swing dia. over slides | mm | Φ420 | ||
Max. workpiece length | mm | 1000/1500/2000/3000 | ||
Spindle | Spindle bore diameter | mm | Φ105(C series) | |
Taper of spindle bore | Φ113 1:20 (C series) | |||
Type of spindle nose | no | ISO 702/II NO.8 com-lock type(C series) | ||
Spindle speeds | R/min | 12 steps 36-1600(C series) | ||
Spindle motor power | KW | 7.5 | ||
Rapid traverse motoe power | KW | 0.3 | ||
Coolant pump motor power | KW | 0.12 | ||
Tailstock | Diameter of quill | mm | Φ75 | |
Max. travel of quill | mm | 150 | ||
Taper of quill (Morse) | MT | 5 | ||
Turret | Tool O.D. size | mm | 25X25 | |
Feed | Max.travel of upper toolpost | mm | 145 | |
Max. Travel of lower toolpost | mm | 310 | ||
X axis feedrate | m/min | 50HZ:1.9 60HZ:2.3 | ||
Z axis feedrate | m/min | 50HZ:4.5 60HZ:5.4 | ||
X feed feeds | mm/r | 65 kinds 0.027-1.07(C series) | ||
Z feed feeds | mm/r | 65 kinds 0.063-2.52(C series) | ||
Metric threads | mm | 22 kinds 1-14(C series) | ||
Inch threads | t.p.i | 25 kinds 28-2(C series) | ||
Module threads | πmm | 18 kinds 0.5-7(C series) | ||
Dia metric pitch threads | DP | 24 kinds 56-4(C series) | ||
Packing size(mm) | 2632/3132/3632/4632*975*1450(C) | |||
weight | Kg | 2200/2400/2600/3000 | ||
