2000VA 1800KW uninterrupted power supply 7AH built in battery Pure sine wave Online UPS
- Category: >>>
- Supplier: Shenzhen Zhongguanda Technology Co. Ltd.
Share on (1601006426010):
Product Overview
Description
Product Description
Features
* High frequency on-line double conversion
* DSP (Digital signal processors) control
* UPS start up without battery
* Wide input voltage range 90V-300V
* Wide input frequency range 40~70Hz
* Generator compatible
* Cold star
* Remote On Of (ROO) function (optional)
* Economic operation mode (ECO)
* 50Hz / 60Hz Frequency auto sensing
* Freguency converter mode: 50Hz input / 60Hz output or 60Hz input / 50Hz output.
* Active input power factor correction, input power factor > 0.99
* Laser printer and ultrasound svstem load acceptable (customized)
* Communications: RS232 (standard), USB / MODBUS/ RS485 / SNMP /AS400 cards (optional)
* Reliable design, made with strong glass fiber base (FR4) double side PCB, well designed ventilatio and conformal coating
* DSP (Digital signal processors) control
* UPS start up without battery
* Wide input voltage range 90V-300V
* Wide input frequency range 40~70Hz
* Generator compatible
* Cold star
* Remote On Of (ROO) function (optional)
* Economic operation mode (ECO)
* 50Hz / 60Hz Frequency auto sensing
* Freguency converter mode: 50Hz input / 60Hz output or 60Hz input / 50Hz output.
* Active input power factor correction, input power factor > 0.99
* Laser printer and ultrasound svstem load acceptable (customized)
* Communications: RS232 (standard), USB / MODBUS/ RS485 / SNMP /AS400 cards (optional)
* Reliable design, made with strong glass fiber base (FR4) double side PCB, well designed ventilatio and conformal coating
Specification
Model | C1K | C1KS | C2K | C2KS | C3K | C3KS | |||||||
Capacity | VA/W | 1kVA/800W | 2kVA/1.6kW | 3kVA/2.4kW | |||||||||
Topology | Double Conversion Online UPS | ||||||||||||
Phase | Single Phase Input Single Phase Output | ||||||||||||
Mains Input | Wiring | L/N+PE | |||||||||||
Rated Voltage | 100V/110V/120V/127AC/ 208/220/230/240VAC | ||||||||||||
Voltage Range | 90~300VAC | ||||||||||||
Frequency Range | 40Hz-70Hz | ||||||||||||
Power Factor | ≥0.99 | ||||||||||||
AC Output | Wiring | L/N+PE | |||||||||||
Output Voltage | 100V/110V/120V/127AC/ 208/220/230/240VAC | ||||||||||||
Output Frequency | 50/60±4Hz(Sync Mode) / 50/60Hz±0.1%(Free Run) | ||||||||||||
Waveform | Pure Sine Wave | ||||||||||||
Battery & Charge | Rated Battery Voltage | 24VDC Internal | 36VDC External | 48VDC Internal | 72VDC External | 72VDC Internal | 96VDC External | ||||||
Battery Capacity | 12V/7AH x2pcs | External Battery Depends | 12V/7AH x4pcs | External Battery Depends | 12V/7AH x6pcs | External Battery Depends | |||||||
Backup Time | >6mins @ Half Load | >6mins @ Half Load | >6mins @ Half Load | ||||||||||
Charging Current | Standard Model with Internal Battery:1A Long Backup Time Model :4A | ||||||||||||
Certifications
Certificates:
Shenzhen ZGD Technology Co., Ltd. has imported high technique controlling facilities in our modern production line. We have successfully attained ISO9001 and CE certifications and comply with RoHS standard.
Application Fields:
Shenzhen ZGD Technology Co., Ltd. provides products and services in many countries around the world. Our products are extensively applied in fields of telecommunication, electric power, railway, finance, securities, hospital, school, aviation, airport, taxation, custom house as well as frontier defense, traffic, education, public security, national defense, energy sources and national key projects. They have won users' consentaneous compliments by complete varieties, reliable quality and perfect post-service.
Operation Principle:
No matter in what condition, we will put our customer at the first place, consider for customers and give them best service to meet their proper needs. We will firmly adhere to the enterprise culture of "uninterrupted power, uninterrupted progress". We will pay much attention to the quality of our products and try our best to make high-rank products.
Shenzhen ZGD Technology Co., Ltd. has imported high technique controlling facilities in our modern production line. We have successfully attained ISO9001 and CE certifications and comply with RoHS standard.
Application Fields:
Shenzhen ZGD Technology Co., Ltd. provides products and services in many countries around the world. Our products are extensively applied in fields of telecommunication, electric power, railway, finance, securities, hospital, school, aviation, airport, taxation, custom house as well as frontier defense, traffic, education, public security, national defense, energy sources and national key projects. They have won users' consentaneous compliments by complete varieties, reliable quality and perfect post-service.
Operation Principle:
No matter in what condition, we will put our customer at the first place, consider for customers and give them best service to meet their proper needs. We will firmly adhere to the enterprise culture of "uninterrupted power, uninterrupted progress". We will pay much attention to the quality of our products and try our best to make high-rank products.
