Image Sensor | 1 / 2.8 "CMOS | ||
Image Size | 1920 × 1080 | ||
Electronic Shutter | 1 / 25 s ~ 1 / 100000 s | ||
Iris Type | DC Iris | ||
Min. Illumination | 0.0026 lux@F1.2,AGC ON; 0 lux with IR 0.005 lux@F1.6, AGC ON; 0 lux with iR | ||
Lens | 2.8~12mm@F1.4, motorized | 7~22mm@F1.6, motorized | |
Field of View | H: 103.4°~32.4°; V:71°~181.5°; D: 111°~36.8° | H: 44°~17.6°; V:25.6°~10°; D: 49.7°~20.2° | |
Lens Mount | Φ14 | ||
Wide Dynamic Range | 120dB | ||
BLC | Yes | ||
HLC | Yes | ||
Defog | Yes | ||
Digital NR | 3D DNR | ||
Angle Adjustment | Pan: 0°~360°; Tilt:0°~90°; Rotation: 0°~360° | ||
Snapshot | Overview and cutout of plate for picture |
White List | 10000 |
Capture Speed Range | 0~70km/h |
Power Supply | DC12V/PoE |
Power Consumption | < 11W |
Operating Environment | - 30 °C ~ 60 °C (-22°F~140°F) Humidity: less than 95 % (non-condensing) |
Dimensions ( mm ) | 279.5 × 100.3 × 88.9 |
Weight ( net ) | Approx. 1.04KG |
Installation | Ceiling mounting; Wall mounting |
