Product Overview
Description
Place of Origin | China |
Product name | abrasion resistant steel sheet wear resistant steel plate |
advantage | wear resistant |
MOQ | 1 kg |
application | Metallurgy, coal, cement, power, mining, building materials |
Packing | Standard packing |
size | Customized |
Certificate | MTC |
Technique | Hot rolled |
The wear resistant steel plate has high wear resistance and good impact performance. It can be cut, bent, welded, etc., and can be connected with other structures by welding, plug welding, bolting, etc., which saves time in the repair site It is widely used in metallurgy, coal, cement, electricity, glass, mining, building materials, bricks and tiles and other industries. Compared with other materials, it has a high cost performance and has been favored by more and more industries and manufacturers. .
chemical composition | ||||||||||||||||||
Grade | C | Si | Mn | P | S | Cr | Ni | Mo | T | |||||||||
≤ | ||||||||||||||||||
NM360 | 0.25 | 0.70 | 1.60 | 0.025 | 0.015 | 0.80 | 0.50 | 0.50 | 0.050 | |||||||||
NM400 | 0.30 | 0.70 | 1.60 | 0.025 | 0.010 | 1.0 | 0.70 | 0.50 | 0.050 | |||||||||
NM450 | 0.35 | 0.70 | 1.70 | 0.025 | 0.010 | 1.1 | 0.80 | 0.55 | 0.050 | |||||||||
NM500 | 0.38 | 0.70 | 1.70 | 0.020 | 0.010 | 1.2 | 1.00 | 0.65 | 0.050 | |||||||||
Mechanical property | ||||||||
Grade | Thickness（mm） | tensile strength(MPa) | Elongation A(%) | Surface Brinell hardness（HBW) | ||||
NM360 | ≤80 | ≥1100 | ≥12 | 330-390 | ||||
NM400 | ≤80 | ≥1200 | ≥10 | 370-430 | ||||
NM450 | ≤80 | ≥1250 | ≥7 | 420-480 | ||||
NM500 | ≤70 | - | - | ≥470 | ||||
Grade comparison | ||
GB | NM360,NM400,NM450,NM500 | |
SS | HARDOX400、HARDOX450、HARDOX500、HARDOX600 | |
DIN | XAR400、XAR450、XAR500、XAR600、Dillidur400、Dillidur500 | |
NBN | QUARD400、QUARD450、QUARD500 | |
NF | FORA400、FORA500、Creusabro4800、Creusabro8000 | |
JIS | JFE-EH360、 JFE－EH400、JFE－EH500、WEL-HARD400、WEL-HARD500 | |
SFS | RAEX400、RAEX450、RAEX500 | |
1. High wear resistance: the wear resistance is more than 15-20 times that of ordinary steel plates, 5-10 times that of low-alloy steel plates, and 2-5 times that of high-chromium cast iron.
2. Better impact performance: the wear-resistant layer resists the wear of the wear medium, and the substrate bears the load of the medium
3. Better heat resistance: The alloy wear-resistant layer is recommended to be used under ≤600℃. If vanadium, molybdenum and other alloys are added to the alloy wear-resistant layer, it can withstand high temperature wear of ≤800℃.
4. Good corrosion resistance: The alloy layer of the wear-resistant composite steel plate contains a high percentage of metallic chromium, so it has certain rust and corrosion resistance.
5. Good processing performance: wear-resistant steel plate can be cut, bent or crimped, welded and punched, and can be processed into various parts
2. Better impact performance: the wear-resistant layer resists the wear of the wear medium, and the substrate bears the load of the medium
3. Better heat resistance: The alloy wear-resistant layer is recommended to be used under ≤600℃. If vanadium, molybdenum and other alloys are added to the alloy wear-resistant layer, it can withstand high temperature wear of ≤800℃.
4. Good corrosion resistance: The alloy layer of the wear-resistant composite steel plate contains a high percentage of metallic chromium, so it has certain rust and corrosion resistance.
5. Good processing performance: wear-resistant steel plate can be cut, bent or crimped, welded and punched, and can be processed into various parts
1.Q: Are you a factory or trading company?
A:We are manufacture factory. And you are welcomed to visit us for inspection. The quality control flow will show you our professional. Also you will enjoy the best price and competitive price.
2.Q: How long is your delivery time?
A:Generally it is within 2-30 days.
3.Q: How do you guarantee the quality of the products?
A:Strict product quality control, quality makes the future.This is the tenet of our factory. Each product from our factory has strict testing procedures, and must be 100% quality before delivery.
4.Q: what can you buy from us?
A: Bulletproof steel plate,Wear resistant steel plate,High strength steel plate,Alloy steel plate，Stainless steel，Safety protection product .etc
5.Q: Can I get some samples?
A: We are glad to provide free samples to you, but we do not offer the freight.
