MODEL NO. | BGP1917-24 | BGP1917-30 | BGP1917-24R | BGP1917-30R |
POWER | 2.4KW | 3KW | 2.4KW | 3KW |
ELECTRIC SUPPLY | 220-240V~50Hz | 220-240V~50Hz | 220-240V~50Hz | 220-240V~50Hz |
SETTING (w) | 30/1200/2400 | 35/1500/3000 | 30/1200/2400 | 35/1500/3000 |
IP RATING | IP20 | IP20 | IP20 | IP20 |
AIR OUTPUT (m3/h) | 460 | 510 | 460 | 510 |
HEATING AREA (m2) | 24 | 30 | 24 | 30 |
PRODUCT MEAS (mm) | 300*267*332 | 300*267*332 | 300*267*332 | 300*267*332 |
PACKING MEAS (mm) | 615*315*685 | 615*315*685 | 615*315*685 | 615*315*685 |
INNER BOX MEAS (mm) | 300*300*330 | 300*300*330 | 300*300*330 | 300*300*330 |
PACKING (pcs/ctn) | 4 | 4 | 4 | 4 |
N.W. (kgs) | 2.75 | 2.75 | 2.75 | 2.75 |
G.W. (kgs) | 3.53 | 3.53 | 3.53 | 3.53 |
QTY/20' (pcs) | 840 | 840 | 840 | 840 |
QTY/40' (pcs) | 1740 | 1740 | 1740 | 1740 |
QTY/40HQ (pcs) | 2400 | 2400 | 2400 | 2400 |







Quality Control:
*IQC (Incoming Quality Control): All In-coming materials and components
*IPQC (In Process Quality Control): Silk-Screen; Metal Stamping; Welding; Coating; Sub-assembling; Final assembly
*LQC (On-Line Quality Control Station): 100% Functionality and Safety Testing; 100% Visual Check of Aesthetics
*QC (Final Quality Control): Pre-Shipment Inspections
*OQC (Out-going Quality Control): Random Inspections; Life Testing
