2023 DELL PowerEdge R740 2u rackmount server Intel Xeon processor computer R740/R740xd Storage Super Computer EMC Server
- Category: >>>
- Supplier: Beijing Shibei Acceleration Technology Co. Ltd.
Share on (1601007199698):
Product Overview
Description
2023 DELL PowerEdge R740 2u rackmount server Intel Xeon processor computer R740/R740xd Storage Super Computer EMC Server
Feature | Technical Specifications |
Processor | Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor |
Memory | • 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s • Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max • Supports registered ECC DDR4 DIMMs only |
Storage controllers | • Internal controllers: PERC H745, HBA355I, S150, H345, H755, H755N • Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB • Boot Optimized Storage Subsystem (BOSS-S1) HW RAID 2 x M.2 SSDs 240 GB or 480 GB • External PERC (RAID): PERC H840, HBA355E |
Drive Bays | Front bays: • Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB • Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB • Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB • Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.84 TB Rear bays: • Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB • Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB |
Power Supplies | • 800 W Platinum AC/240 mixed mode • 1100 W Titanium AC/240 mixed mode • 1400 W Platinum AC/240 mixed mode • 2400 W Platinum AC/240 mixed mode |
Cooling Options | Air cooling, optional processor liquid cooling |
Fans | • Standard fan/High performance SLVR fan/High performance GOLD fan • Up to six hot plug fans |
Dimensions | • Height – 86.8 mm (3.41 inches) • Width – 482 mm (18.97 inches) • Depth – 758.3 mm (29.85 inches) - without bezel 772.14 mm (30.39 inches) - with bezel |
Form Factor | 2U rack server |
Embedded Management | • iDRAC9 • iDRAC Service Module • iDRAC Direct• Quick Sync 2 wireless module |
Bezel | Optional LCD bezel or security bezel |
OpenManage Software | • OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage SupportAssist plugin • OpenManage Update Manager plugin |
Mobility | OpenManage Mobile |
GPU Options | Up to two double-width 300 W, or four single-width 150 W, or six single-width 75 W accelerators |
Front Ports | • 1 x Dedicated iDRAC Direct micro-USB • 1 x USB 2.0 • 1 x VGA |
Rear Ports | • 1 x USB 2.0 • 1 x Serial (optional) • 1 x USB 3.0 • 2 x RJ-45 • 1 x VGA |
Internal Ports | 1 x USB 3.0 |
PCIe | Up to 8 x PCIe Gen4 slots (up to 6 x16) with support for SNAP I/O modules |
