Difference/Same Between HK Origianl & OEM | ||||
Options | Hk | OEM | ||
Manufacturer | Hk Original | |||
LOGO | Hk Original | Your Owm LOGO | ||
Function | All of the Function Same | |||
Software | The Same APP & Software | |||
Accessories | All of the Accessories are Same as Hik Original | |||




Camera | |
Image Sensor | 1/3" Progressive Scan CMOS |
Min. Illumination | Color: 0.001 Lux @(F1.0, AGC ON), 0 Lux with white light |
Shutter Speed | 1/3 s to 1/100, 000 s |
Slow Shutter | Yes |
Wide Dynamic Range | 120 dB |
Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
Lens | |
Focal Length & FOV | 2.8 mm, horizontal FOV 96.5°, vertical FOV 50.8°, diagonal FOV 113.9° |
4 mm, horizontal FOV 75.8°, vertical FOV 40.8°, diagonal FOV 89.1° | |
Lens Mount | M12 |
Focus | Fixed |
Aperture | F1.0 |
Image | |
Image Settings | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser. |
Day/Night Switch | Day, Night, Auto, Schedule |
Image Enhancement | BLC, 3D DNR |
Interface | |
Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
On-Board Storage | -UF: Built-in memory card slot, support microSD card, up to 256 GB |
Built-In Microphone | -UF: Yes |
Hardware Reset- | UF: Yes |
Event | |
Basic Event | Motion detection, video tampering alarm, exception |
General | |
Linkage Method | Upload to FTP/memory card (-UF), notify surveillance center, send email, trigger recording (-UF), trigger capture |
Camera Material | Aluminum alloy body |
Camera Dimension | Ø76.6 mm × 164.4 mm (Ø3" × 6.5") |
Package Dimension | 234 mm × 120 mm × 117 mm (9.2" × 4.7" × 4.6") |
Camera Weight | Approx. 430 g (0.95 lb.) |
With Package Weight | Approx. 648 g (1.42 lb.) |
Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing) |
Startup And Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing) |
Web Client Language | English, Ukrainian |
General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
Firmware Version | V5.5.122 |
Power Consumption And Current | 12 VDC, 0.4 A, max. 5 W |
PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.15 A, max. 6.5 W | |
Power Supply | 12 VDC ± 25% |
PoE: 802.3af, Class 3 | |
Power Interface | Ø5.5 mm coaxial power plug |
Approval | |
EMC | FCC SDoC (47 CFR Part 15, Subpart B); |
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); | |
RCM (AS/NZS CISPR 32: 2015); | |
KC (KN 32: 2015, KN 35: 2015) | |
Safety | UL (UL 60950-1); |
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); | |
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); | |
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) | |
Environment | CE-RoHS (2011/65/EU); |
Reach (Regulation (EC) No 1907/2006) | |
Protection | IP67 (IEC 60529-2013) |
