Product Overview
Description
Product Description
Item | Unit | Data | ||
Equipped with breaker | ||||
VS1(ZN63A-12) | VD4 | |||
Rated voltage | kV | 12 | 12 | |
1min working frequency endurable voltage | kV | 42 | 42 | |
Shock endurable rated voltage | kV | 75 | 75 | |
Rated frequency | Hz | 50 | 50 | |
Rated current | A | 630/1250/1600/2000/2500/3150/4000/5000 | ||
Branch bus bar rated current | A | 630/1250/1600/2000/2500/3150/4000/5000 | ||
Rated short time endurable current(vitrual value) | kA | 16/20/31.5/40/50 | 16/20/31.5/40/50 | |
Rated peak endurable voltage | kA | 40/50/63/80/100/125 | 40/50/63/80/100/125 | |
Rated short-circuit duration | s | 4 | ||
Protection degree | IP4X / IP2X | |||
Quality | kg | 700~1200 | 700~1200 | |
