  • 2024 Deye SUN 16K SG01LP1 EU Solar Inverter 16kw Hybrid Inverter Storage Energy
2024 Deye SUN 16K SG01LP1 EU Solar Inverter 16kw Hybrid Inverter Storage Energy
2024 Deye SUN-16K-SG01LP1-EU Solar Inverter 16kw Hybrid Inverter Storage Energy
2024 Deye SUN-16K-SG01LP1-EU Solar Inverter 16kw Hybrid Inverter Storage Energy
2024 Deye SUN-16K-SG01LP1-EU Solar Inverter 16kw Hybrid Inverter Storage Energy
2024 Deye SUN-16K-SG01LP1-EU Solar Inverter 16kw Hybrid Inverter Storage Energy

2024 Deye SUN 16K SG01LP1 EU Solar Inverter 16kw Hybrid Inverter Storage Energy

Share on (1601009230680):


Price:$2,500.00 - $2,600.00

Quantity:


Product Overview

Description



Specification




Model
SUN-8K-SG04LP3
SUN-10K-SG04LP3
SUN-12K-SG04LP3
Battery Input Data
Battery Type
Lead-acid or Lithium-ion
Battery Voltage Range(V)
40~60V
Max. Charging Current (A)
190A
210A
240A
Max. Discharging Current (A)
190A
210A
240A
Charging Curve
3 Stages / Equalization
External Temperature Sensor
Optional
Charging Strategy for Li-Ion Battery
Self-adaption to BMS
PV String Input Data
Max. DC Input Power (W)
10400W
13000W
15600W
PV Input Voltage (V)
550V (160V~800V)
MPPT Range (V)
200V-650V
Start-up Voltage (V)
160V
PV Input Current (A)
13A+13A
26A+13A
26A+13A
No.of MPPT Trackers
2
No.of Strings Per MPPT Tracker
1+1
2+1
2+1
AC Output Data
Rated AC Output and UPS Power (W)
8000W
10000W
12000W
Max. AC Output Power (W)
8800W
11000W
13200W
Peak Power (off grid)
2 times of rated power, 10 S
AC Output Rated Current (A)
12A
15A
18A
Max. AC Current (A)
18A
23A
27A
Max. Continuous AC Passthrough (A)
50A
50A
50A
Output Frequency and Voltage
50 / 60Hz; 400Vac (three phase)
Grid Type
Three Phase
Current Harmonic Distortion
THD<3% (Linear load<1.5%)
Efficiency
Max. Efficiency
97.60%
Euro Efficiency
97.00%
MPPT Efficiency

99.90%
Certififications and Standards
Grid Regulation

IEC61727, IEC62116, IEC60068, IEC61683, NRS 097-2-1
Safety EMC/Standard
IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-11, IEC61000-3-12


Model
SUN-5K-SG01LP1
SUN-6K-SG01LP1
SUN-7.6K-SG01LP1
SUN-8K-SG01LP1
Battery Input Data
Battery Type
Lead-acid or Lithium-ion
Battery Voltage Range (V)
40-60V
Max. Charging Current (A)
120A
135A
190A
190A
Max. Discharging Current (A)
120A
135A
190A
190A
Charging Curve
3 Stages / Equalization
External Temperature Sensor
Optional
Charging Strategy for Li-Ion Battery
Self-adaption to BMS
PV String Input Data
Max. DC Input Power (W)
6500W
7800W
9880W
10400W
PV Input Voltage (V)
370V (100V~500V)
MPPT Range (V)
125V-425V
Start-up Voltage (V)
150V
PV Input Current (A)
11A+11A
22A+11A
22A+12A
22A+22A
No.of MPPT Trackers
2
No.of Strings Per MPPT Tracker
1+1
2+1
2+2
2+2
AC Output Data
Rated AC Output and UPS Power (W)
5000W
6000W
7600W
8000W
Max. AC Output Power (W)
5500W
66000W
8360W
8800W
Peak Power (off grid)
2 times of rated power, 10 S
AC Output Rated Current (A)
20.8A
25A
31.7A / 33A
33.4A / 35A
Max. AC Current (A)
22.9A
27.5A
34.9A / 36.3A
36.7A / 38.5A
Max. Continuous AC Passthrough (A)
35A
40A
50A
50A
Output Frequency and Voltage
50 / 60Hz; 220/230/240Vac (three phase)
Grid Type
Single Phase
Current Harmonic Distortion
THD<3% (Linear load<1.5%)
Efficiency
Max. Efficiency
97.60%
Euro Efficiency
97.00%
MPPT Efficiency
99.90%
Certififications and Standards
Grid Regulation
IEC61727, IEC62116, IEC60068, IEC61683, NRS 097-2-1
Safety EMC/Standard
IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-11, IEC61000-3-12


FAQ


Q1: How to install and use the solar inverter?
A1: We have the English teaching manual and videos; All the videos about every step of machine Disassembly, assembly, operation will be sent to you.

Q2: What if I don't have import experience?
A2: We have reliable forwarder agent which can ship items to you by sea/air/Express to your doorstep. Any way, we will help you choose the most suitable shipping service.

Q3: How is your technical support?
A3: We provide online service through Whats app/ Skype/ Wechat/ Email. Any problem after delivery, we will offer you video call anytime, our engineer will also go to oversea help our customers if necessary.

Q4: Can you get the the solar inverter customized for us?
A4: Of course, brand name, machine color, designed unique patterns
available for customization.

Q5: How can I make sure it's a secure transaction?
A5: Alibaba can protect buyers' interest, all of our transation will go through alibaba platform.As you finish the payment, the money will go directly to Alibaba bank account.After we send your the items and you comfirm the detailed information, Alibaba will release us the money.
