Basic Information | ||||||
Truck Dimension | 9600*2485*3670 | Box Dimension | 7120*2385*2225 | |||
Truck Model | YZRQL5150XWQFRJ | Truck type | Vans | |||
Drive Type | 4X2 | Wheelbase(mm) | 5550 | |||
Box length Level (M | 7.1 | Engine | 6HK1-TCL | |||
Transmission | 6-speed gearbox | Truck length(mm) | 9600 | |||
Truck width (mm) | 2485 | Truck height(mm) | 3670 | |||
Front tread (on wheel )(mm) | 19600 | Rear tread (on wheel )(mm) | 1855 | |||
Curb weight (kg) | 7650 | Rated loading weight(kg) | 7155 | |||
Gross weight | 16000 | Max. Speed(km/h) | 95 | |||
Origin | China | Tonnage class | Heavy duty | |||
Approach angle (º) | / | Departure angle (º) | / | |||
Front/rear suspension (mm) | / | |||||
Engine Parameters | ||||||
Engine model | 6HK1-TCL | Engine brand | Isuzu | |||
Engine class | / | Cylinder number | 6 | |||
Fuel type | Diesel | Cylinder arrangement | inline | |||
Displacement (L) | 7.79 | Emission standard | Euro 5 | |||
Max. output power(kw) | 176 | Max.Horsepower(hp) | 240 | |||
Max. Torque(N.m) | / | Max. torque speed(RPM) | / | |||
Rated Rotated Speed(RPM) | / | |||||
Cargo box parameters | ||||||
Cargo box form | van | Length (mm) | 7120 | |||
Width (mm) | 2385 | Height (mm) | 2225 | |||
Cab parameters | ||||||
occupancy | 3person | Seat rows | Single | |||
Transmission parameters | ||||||
Transmission Model | 6-speed gearbox(isuzu MLD-6Q) | Shift mode | Manual | |||
forward gear | 6 | reverse gear | 1 | |||
Chassis parameters | ||||||
Allowable front axle load(kg) | 6300 | Allowable rear axle load(kg) | 13000 | |||
Number of spring plates | 8/10+6 | Fuel tanker | 200L | |||
Tires | ||||||
Tire Specification | 295/80R22.5 | Number of tires | 6 | |||
Controls | ||||||
ABS anti-lock | √ | |||||
Internal Configuration | ||||||
multifunction steering wheel | √ | Forms of air-conditioning regulation | Manual | |||
power window | √ | Electronic central locking | √ | |||
Multimedia Configuration | ||||||
radio | √ | |||||
Brake | ||||||
Vehicle Brake Type | pneumatic brake | parking brake | Hand brake | |||
