Product Overview
Description
Emerson Combined communication power supply NetSure731CC2-X3/X4 switching power supply 48V600A
Emerson NetSure731cc2-x3 high frequency DC power supply parameters:
Vertiv NetSure, PS48 series combined power supply system is a combined communication power supply system designed to meet the power supply requirements of communication networks by adopting DSP control technology and integrating many years of development and online operation experience of Vertiv technology. The system is mainly composed of rectifier modules, monitoring modules, AC/DC power distribution units, lightning protection systems, etc. It has the characteristics of high reliability, high efficiency, energy saving, and intelligence.
Value characteristics
High reliability Wide voltage input range 85~300Vac, super power grid and oil engine adaptability Ultra-wide operating temperature range -40-65℃, strong environmental adaptability, suitable for various areas The lightning protection design on the AC side and DC side improves the lightning protection capability of the system With Walk-in function, avoid impact on the front transformer and oil machine when starting |
High efficiency and energy saving Common module efficiency > 93%, high module efficiency > 96%, saving users' electricity expenses There are hibernation and high-efficiency - universal effect module mixed energy saving technology, improve the operation efficiency Intelligent fan speed control function to reduce system loss The rectifier module has a high power density and reserves more space for cable routing and operation |
intelligentize It has communication interface such as RS232 dry contact. Flexible networking The rectifier module has an independent ID identification function, which is convenient for the user's asset management Perfect battery management function, effectively extend battery life |
Easy to use The module is hot-swappable without damage, and can be maintained online, convenient and fast Full frontal maintenance design |
Application scenario Communication macro base station Communication microbase station Distributed base station Integrated access point |
| disposition | NetSure 731CC2-X3 | NetSure 731CC2-X4 | |
| System capacity | 600A | ||
| Monitoring module | M522S | ||
| Rectifier module | 12x50A(R48-3000A3, R48-3000e3 optional) | ||
| Ac distribution | input | 1x100A/3P(Circuit breaker) | 1x100A/3P(Circuit breaker) |
| exportation | 1x16A/1P1x16A/3P(Circuit breaker) | 1x16A/1P1x16A/3P(Circuit breaker) | |
| Ac lightning protection | Level C | Level C | |
| Dc distribution | Battery power-off | 4x16A/1P(Circuit breaker) | 2x63A/1P, 2x32A/1P.2x10A/1P(Circuit breaker) |
| Load power-off | 4x100A(Fuse) 4x63A/1P.6x32A/1P(circuit breaker) | 4x100A(Fuse) 6x63A/1P, 2x32A/1P 2x16A/1P(Circuit breaker) | |
| Dc lightning protection | In=10kA | In-10kA | |
| Battery access | 2x500A(Fuse) | 2x500A(Fuse) | |
| Dry contact | Five alarm dry contacts | ||
| Select accessories | Top cover, temperature compensation cable, module filler panel, fuse extractor, etc | ||
| Mechanical parameter | 600mm(W)x400mm(D)x1600mm(H) | ||
| Weight (kg) | NetSure731CC2s110(includes rectifier module) | ||
