Price:$155.00 - $175.00

Quantity:


Product Overview

Description



Product Description




Products Features:
1, Single-leaf or double-leaf: operated by remote controller or control panel, it can open and close by single-leaf or double
–leaf.

2,Automatically stop when meet obstacles: It will stop by itself to ensured the safety if there has someone or something shall stop its running. Resistance is set in the control box.

3,Infrared sensor protected: Installed infrared sensor, it will stop and run back by itself if someone or something in there.

4, Open and close in order: adapt to the seal gate.

5, Auto-close: After open the gate, it will automatically close in the right time.

6, Soft start and stop: it can protect gate and gate opener makes its running normal.


Product Paramenters




Model
RS-G01 Series
Driving method
Screw driven piston type
Operating Voltage
DC24V for normal speed
/
DC12V for cushioning speed
Max.Output power
80W per driver
Max.piston stroke
30cm
Max.piston speed
3cm/sec
Operating cycle
12second per 90(approx)
Max. single-leaf weight
300kg per leaf
Max. single-leaf length
2.1M(7 feet)
DSPS device
Electronic timing tracker
Gearbox
Planetary gear
Safety clutch
Electronic current sensing
Release Key
with
Backup battery
12V /2.6A
Safety barrier
Photocells(optional)
Main supply
AC110V/220V,60Hz/50Hz
Electronic controller
Microcomputer based
Remote controller
UHF Digital PWM type
Temperature
-20 to +80C
Protection Class
IP54
