Manufacturer Nickel Based Welding Wire Alloy ERNiCrMo 4 Weld Wire For Hastelloy C276
- Category: >>>
- Supplier: Qinghe County Liansheng Welding Materials Co. Ltd.
Share on (1601010778262):
Product Overview
Description
Company Profile
Qinghe County Liansheng Welding Materials Co., LTD. founded in 2002, it is an enterprise specializing in the production and development of welding materials. The annual production of various types of welding electrodes, welding wires, fluxes, welding belts totaled more than 30,000 tons, and sales exceeding 650 million yuan.
The main products are: carbon steel welding electrode, stainless steel electrode, cast iron electrode, wear-resistant surfacing electrode, nickel based electrode, cobalt alloy electrode, aluminum electrode, silver electrode, gas shielded welding wire, argon arc welding wire, flux-cored welding wire, submerged arc welding wire, stamping wire, welding strip, flux. All products have passed ISO9001:2015 certification,CCS certification,AB certification,DB certification,SGS certification.
The main products are: carbon steel welding electrode, stainless steel electrode, cast iron electrode, wear-resistant surfacing electrode, nickel based electrode, cobalt alloy electrode, aluminum electrode, silver electrode, gas shielded welding wire, argon arc welding wire, flux-cored welding wire, submerged arc welding wire, stamping wire, welding strip, flux. All products have passed ISO9001:2015 certification,CCS certification,AB certification,DB certification,SGS certification.
Our Advantages
Product Description
AWS A5.14 ERNiCrMo-4
Introduction：
The bead has excellent crack resistance and good corrosion resistance under many corrosive environmental conditions, especially the pitting corrosion and crevice corrosion resistance.
Introduction：
The bead has excellent crack resistance and good corrosion resistance under many corrosive environmental conditions, especially the pitting corrosion and crevice corrosion resistance.
Purpose：
The product is applicable for the welding of Ni-Cr-Mo alloy, and can also be used for dissimilar welding of steel and nickel-based alloy and surfacing welding of steel.
The product is applicable for the welding of Ni-Cr-Mo alloy, and can also be used for dissimilar welding of steel and nickel-based alloy and surfacing welding of steel.
Chemical Composition(%)
Test item | C | Mn | Fe | Si | Cu | Ni | Co | |
Example value | 0.008 | 0.35 | 6.0 | 0.05 | 0.03 | 56.8 | 0.03 | |
Test item | Cr | Mo | W | V | S | P | ||
Example value | 15.9 | 16.55 | 3.69 | 0.02 | 0.002 | 0.005 | ||
Mechanical properties of deposited metal
Test item | Rm (MPa) | ReL/Rp0.2 (MPa) | A (%) | Impact property | ||
Example value | 749 | 497 | 41 | ℃ | KV2/J | |
-196 | 104.6 | |||||
Reference current (DCEP/DCEN)
Diameter of welding wire mm | Φ0.8 | Φ1.0 | Φ1.2 | Φ1.6 |
Welding current A | 70-190 | 100-200 | 160-280 | 200-350 |
Precautions:
1. Before welding, impurities such as pollutants and oxides on the welding edge of the work piece and the surface of the welding wire must be cleaned;
2. During the welding process, the weld gap should be cleaned in time to prevent slag inclusion;
3. Operating with small heat input as possible, and keeping the gap temperature below150℃.
1. Before welding, impurities such as pollutants and oxides on the welding edge of the work piece and the surface of the welding wire must be cleaned;
2. During the welding process, the weld gap should be cleaned in time to prevent slag inclusion;
3. Operating with small heat input as possible, and keeping the gap temperature below150℃.
Specification
item | value |
Warranty | 3 years |
Customized support | OEM, ODM, OBM |
Place of Origin | China |
Hebei | |
Brand Name | DIBO |
Model Number | AWS A5.14 ERNiCrMo-4 |
Material | Nickel alloy |
Diameter | 0.8,0.9,1.0,1.2,1.6,2.0,2.4,3.0,4.0 |
Melting Point | standard |
Weight | 15kg/spool,5kg/box,20kg/carton |
Application | Ni-Cr-Mo alloy,steel and nickel-based alloy and surfacing welding of steel. |
Flux Content | international standards |
Product name | Nickel alloy welding wire AWS A5.14 ERNiCrMo-4 |
Advantage | good corrosion resistance under many corrosive environmental conditions |
Sample | Avaiable |
Keyword | MIG TIG WELDING WIRE ROD |
OEM | Accept OEM |
Certification | ISO9001:2015 |
Color | Sliver |
Shape | MIG spool and 1M Tig Rod |
Quality | High Quality(ISO) |
Packing & Delivery
15kg/spool/carton or 5kg/box , 20kg/carton
FAQ
1.who are we?
We are based in Hebei, China, start from 2010,sell to Southern Europe(14.00%),Northern Europe(12.00%),South Asia(9.00%),Southeast Asia(8.00%),Oceania(8.00%),Mid East(8.00%),Africa(7.00%),Eastern Europe(6.00%),Central America(6.00%),North America(5.00%),South America(5.00%),Western Europe(5.00%),Domestic Market(5.00%),Eastern Asia(2.00%). There are total about 200 people in our company.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Welding Electrode,Welding Wire,Weld Flux
4. why should you buy from us not from other suppliers?
we are the largest manufacturer of welding materials in China, with a national technology center, 20 technical r&d personnel and we have more than 500 product categories, sold in more than 60 countries.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card;
Language Spoken:English,Chinese,Spanish,Japanese,Russian
We are based in Hebei, China, start from 2010,sell to Southern Europe(14.00%),Northern Europe(12.00%),South Asia(9.00%),Southeast Asia(8.00%),Oceania(8.00%),Mid East(8.00%),Africa(7.00%),Eastern Europe(6.00%),Central America(6.00%),North America(5.00%),South America(5.00%),Western Europe(5.00%),Domestic Market(5.00%),Eastern Asia(2.00%). There are total about 200 people in our company.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Welding Electrode,Welding Wire,Weld Flux
4. why should you buy from us not from other suppliers?
we are the largest manufacturer of welding materials in China, with a national technology center, 20 technical r&d personnel and we have more than 500 product categories, sold in more than 60 countries.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card;
Language Spoken:English,Chinese,Spanish,Japanese,Russian
