200cc truck utility vehicle 2m Cargo Motor Tricycle Manual Clutch Water Cooled Delivery Bike electric tricycles cargo bike frame
- Category: >>>
- Supplier: Chongqing Ronben International Co. Ltd.
Share on (1601012474191):
Product Overview
Description
Product Introduction
Specification
Engine | ||
Engine Displacement (ml) | 196.98 | |
Engine Type | Water cooled,Singlecylinder,4-stroke | |
Starting Mode | Kick/Electric | |
Clutch | Manual, wet, multiple | |
Compression Ratio | 9.0:1 | |
Max Power: | 12.0kw/8000r/min±425 r/min | |
Max Torque | 15.0N.m/6000r/min±350 r/min | |
Lubrication | Pressure splash | |
Ignition Type | CDI | |
Tricycle Body | ||
Use For | Cargo | |
L×W×H (mm) | 3290×1200×1490 | |
Wheel Base (mm) | 2380 | |
Wheel Tread (mm) | 1145 | |
Cargo box | 1400*2000 | |
Max speed | 60km/h | |
Load Capacity | 1350kg | |
Drive Mode | Shaft Drive | |
Tricycle framework | 40x80mm | |
Emissions Standard | GB14621-2011,GB14622-2007 | |
Body Type | Open | |
N.W | 398kg | |
G.W | 418kg | |
Front shock absorber | Storm TAIZI type | |
Leaf spring | 2+2 pcs | |
Brake (Front/rear) | Drum brake/Drum brake | |
Wheel (front/rear) | 3.25-16/4.50-12 | |
Braking mode (Front/rear) | Hand/Foot | |
Rear axle | Normal rear axle(brake assembly dia.180mm) | |
Fuel type | Gasoline | |
Meter | TAIZI | |
Storage battery | 9A | |
Colour | Red/Yellow/Blue/Other colors | |
QTY/40FT HQ:(units) | CKD 48 units/1x40'HQ container | |
Packaging | Carton, CKD | |
Packaging | Carton, CKD | |
Packing & Delivery
We offer two packaging methods. 1. SKD 2. CKD. To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
We specialize in import and export of motorcycles, geneator, diesel engines and spare parts. Our business scope covers West Africa, South America, East Europe and other regions.
Products Description
1. Technology, quality, and service are the embodiment of an enterprise's overall capacity,Qiyuan's aim is to become the
motorcycle engine industry's model of service featuring specialization, standardization and human orientation, so as to develop a good mode for value creation through technology, brand formation through quality, and market expansion through service.
2. ZS CG200cc provides consistent and powerful and stable power output.
3. 1.4*2m stronger cargo box carry more goods.
4. The tricycle is small in size and can flexibly cross narrow roads.
5. 1 year or 6000 Km quality guarantee demonstrates our confidence in our products and our commitment to our customers.
6. 48 sets CKD packing help customers save transportation costs and avoid damage during the transportation.
FAQ
Q1. How long for delivery time?
A1. Our delivery time is 30- 40days.
Q2. Which colors will be available?
A2. Almost all the popular colors are available,or we can customize the color you want for you.
Q3. Can I mix different models in one full container order?
A3. Yes, and we can give you more selections to make one full container.
Q4. Why choose us?
A4. Provide you professional service 2. Have stable cooperation shipping forwarder
Q5. What is the price of your products ?
A5. Pls contact with our sales for detailed offer.
A1. Our delivery time is 30- 40days.
Q2. Which colors will be available?
A2. Almost all the popular colors are available,or we can customize the color you want for you.
Q3. Can I mix different models in one full container order?
A3. Yes, and we can give you more selections to make one full container.
Q4. Why choose us?
A4. Provide you professional service 2. Have stable cooperation shipping forwarder
Q5. What is the price of your products ?
A5. Pls contact with our sales for detailed offer.
