XCMG Official XR150DIII Used Small Rotary Drilling Rig Machine for sale

* It adopts the dedicated hydraulic retractable crawler chassis and large diameter slewing bearing to provide extraordinary
stability and transport convenience.

* It adopts the electric control turbo-supercharged engine to provide strong power and conformity with Euro III emission standard.

* With the hydraulic pressure system adopted threshold power control and negative flow control,the system acquired high efficiency
and higher energy conservation.

Advantages and highlights:
1.Offer Test Report of Professional Institute.
2.Details Of Maintenance And Repair Items Included.
3.Price Concessions.
4.Official Factory Sourcing.
5.Reconditioning Directly From XCMG.
6.Vehicle Condition of Perfection.
7.XCMG Official Endorsement.
8.SGS Provides The Third-Party Inspection Certificate.


Specification


Description
Unit
Parameter value
Max. drilling diameter
mm
1500
Max. drilling depth
m
56
Allowable luffing scope (from center of drill rod to slewing center)
mm
3250～3650
Drilling rig dimension in working condition (L × W × H)
mm
7550×4200×19040
Drilling rig dimension in transport condition (L × W × H)
mm
13150×2960×3140
Weight of overall unit (standard configuration, excluding drilling tool)
t
49
Engine
Model
QSB7
Rated power/speed
kW
150/（2050r/min）
Max. working pressure of hydraulic system
MPa
35
Rotary drive
Max. torque
kN •m
150
Rotational speed
r/min
7～33
Crowd cylinder
Max. Pushing force
kN
120
Max. Pulling force
kN
160
Max.stroke
mm
3500
Main winch
Max.pulling force
kN
160
Max. single-rope speed
m/min
72
Diameter of the steel wire rope
mm
26
Auxiliary winch
Max.pulling force
kN
50
Max. single-rope speed
m/min
60
Diameter of the steel wire rope
mm
16
Rotary table slewing angle
°
360
Traveling
Max. traveling speed of the overall unit
km/h
2.1
Max. climbable gradient of the overall unit
%
40
Crawler
Width of crawler plate
mm
700
External width of crawler (min.-max.)
mm
2960～4200
Center distance between two longitudinal wheels of crawler
mm
4310
Average ground pressure
kPa
83
