AlSi10Mg Spherical Aluminum based alloy powder
- Category: >>>
- Supplier: Shanghai Ximeng New Material Technology Co. Ltd.
Share on (1601012583771):
Product Overview
Description
AlSi10Mg Spherical Aluminum albased alloy powder
Product Description
Product performance:
Aluminum alloy has low density, but relatively high strength, approaching or surpassing high-quality steel, good plasticity, and can be processed into various profiles with excellent conductivity, thermal conductivity, and corrosion resistance. It is widely used in industry, and its usage is only second to that of steel. Some aluminum alloys can achieve good mechanical properties, physical properties, and corrosion resistance through heat treatment. The hard aluminum alloy AI-Cu-Mg system generally contains a small amount of Mn and can be strengthened through heat treatment. Its characteristic is high hardness but poor plasticity. Superhard aluminum Al-Cu-Mg
Applicable process:
XMMAT® Powder is mainly used in laser/electron beam augmentation manufacturing (SLM/EBM), powder metallurgy (PM) and other processes.
Applicable equipment:
XMMAT® Powder can be used in various types of metal 3D printers, including laser melting equipment of Renishaw, Renishaw, Germany EOS (EOSINT M series), Concept Laser, 3D systems, etc.
Application Fields:
Aluminum alloy powder used in Aerospace, household appliances, electric heaters, infrared devices
Product Introduction：
Brand name | Chemical Composition（wt%） | APS | ||
Main Element | Impurity content | |||
AlSi10Mg(ZL104) | Si：10-11 Mg：0.4-0.45 Fe：0.14-0.55 Cu：＜0.05 Mn：＜0.01-0.45 Al：Bal | Ni：＜0.01-0.05 Zn：＜0.01-0.1 Pb：＜0.01-0.05 Sn：＜0.01-0.05 Ti：＜0.01-0.15 O：≤0.05 | 15-45μm 15-53μm 53-120μm 53-150μm | |
AlSi12(ZL102) | Fe：≤0.25 Mn：≤0.1 Si：11.00-13.00 Zn：≤0.2 Al：Bal | Cu：≤0.3 Mg：≤0.1 Pb：≤0.02 Sn：≤0.02 O：＜0.05 | 15-45μm 15-53μm 53-120μm 53-150μm | |
AlSi7Mg(ZL101) | Cu：1.4-2.0 Mn：0.2-0.6 Mg：1.8-2.8 Cr：0.1-0.25 Zn：5.0-7.0 Al： Bal | Si：0.5 Fe：0.5 Ti：0.1 O：＜0.05 Res Each：0.05 ResTotal：0.1 | 15-45μm 15-53μm 53-120μm 53-150μm | |
2A12 | Cu：3.8-4.9 Mn：0.3-0.9 Mg：1.2-1.8 Al：Bal | Si：0.5 Fe：0.5 Ni：0.1 Zn：0.3 Ti：0.15 O：≤0.05 Res Each：0.05 Res Total：0.1 | 15-45μm 15-53μm 53-120μm 53-150μm | |
2A14 | Cu：3.9-4.8 Mn：0.4-1.0 Mg：0.4-0.8 Si：0.6-1.2 Al：Bal | Fe：0.7 Ni：0.1 Zn：0.3 Ti：0.15 O：≤0.05 Res Each：0.05 Res Total：0.1 | 15-45μm 15-53μm 53-120μm 53-150μm | |
Packing & Delivery
No.1 | Packing detail | 100g/bag, 500g/bag, 1kg/bag, 25kgs/bag/drum or according to your requirements. |
No.2 | Delivery Time | In 2-3 days after receive the payment. |
No.3 | Shipping methods | ≤500KGS By DHL/TNT/Fedex/EMS;>500KGS By Sea;or according requirements. |
No.4 | Storage | It should be stored in dry, cool and sealing of the environment. |
