Electric Battery Power Sightseeing Bus 17 Seaters Electric Shuttle Bus Passenger Car With Doors
- Category: >>>
- Supplier: Zhejiang Shanyuan New Energy Technology Co. Ltd.
Share on (1601012774709):
Product Overview
Description
Product Description
Electric control | Imbor AC 72V |
battery | 6V200AH/ only, 12 non-dimensional batteries |
Electric machine | 10KW AC motor |
charger | Portable intelligent charger |
Charging time | 8-10 hours (80% discharge rate) |
Basic body color | White, green, yellow, blue (customized according to customer needs) |
Car body | Steel frame + sheet metal (FRP) shell |
frame | High strength carbon steel frame with anti-rust treatment |
tyre | Steel hub 165R13C vacuum radial tire |
Rated occupant | 17 people |
Dimensions Length * width * height | 5970×1540×2040mm |
Vehicle equipment mass | 1460kg |
Vehicle load | 1445kg |
Front and rear wheel bases | 1270/1225mm |
wheelbase | 3360mm |
Minimum turning radius | 7.5 m |
Minimum ground clearance | 150mm |
Braking distance | ≤6m |
Charge input voltage | 220v |
Maximum travel speed | ≤30km/h |
Driving range | 100~110km |
Maximum gradient | 0.05 |
Product Display
Please Consult For More Product Details.
