Front Radar Sensor - S1
The long range radar is 77GHz millimeter wave radar system which installed on front of the vehicle for forward looking functions especially made for Highly Automated Driving.
S1 is first generation front radar of EI company which provides integrated FCW, ACC, AEB features and can support up to L3 ADAS features.
★Compact Design, Light
★Low Energy Consumption
★Low Cost
★Customized Development
★Long Detection Range
★Low Energy Consumption
★Low Cost
★Customized Development
★Long Detection Range
Antenna | 3Tx/4Rx | Weight | 80g |
Max. Detection Range | 250m | Size | 70 x 70 x 14.8 mm |
Min. Detection Range | 0.8m | Interface | CAN + CAN-FD, 2 Channels |
Distance Accuracy | 0.3m | Voltage | 9~36V |
Distance Resolution | 1.25m | Power | 3W |
FoV | -30~30 | Temperature | -40 ~ +85 |
Angle Accuracy | 0.3 | Anti-Dusk/Water | IP69K + IP67 |
Angle Resolution | 4 | Installation | Bracket Mounting |
Velocity Detection Range | -234km/h ~ +108km/h | Power Supply Model | KL15 or KL30 Compatible |
Velocity Detection Accuracy | 0.05m/s | Frequency | 76 GHz ~ 77 GHz |
Velocity Detection Resolution | 2m/s | Self-Integrated Feature | FCW, ACC, AEB |
Max. Detection Output | 200 | Connector | Molex |
Max. Object Output | 40 | Blockage Detection | Supported |
