Single Colors Plastic Bag Label Printer Flexo Printing Machine Flexographic Printer
$34,000.00-35,000.00
High Speed Flexographic Printing Machine China Flexo PP Non Woven Fabric Printing Machine Ci Flexo Printing Machine Manufacturer
- Category: >>>
- Supplier: Zhejiang Kete Machinery Co. Ltd.
Share on (1601014359122):
Product Overview
Description
High Speed Flexographic Printing Machine China Flexo PP Non Woven Fabric Printing Machine Ci Flexo Printing Machine Manufacturer
This Cl Flexo Printing Machine Is Suitable for Roll to Roll Printing PP Woven Fabric For Both Side Together, And Other Similar Roll Type Materials.
● Unwind and Rewind with Auto Tension Control
● With Ceramic Anilox Roller
● Use Servo Motor Drive System
● Printing Cylinder Life uses a Hydraulic System
● With Shaft Type Auto Loading
● Optional: Auto Color Register System
● Optional: Ceramic Anilox Roller Ultrasonic Clean Machine
● PLC Touch Screen Control System
● With Belt for Transfer
● Double Side Enclosed Type Doctor Blade
● With Web Video Inspection
● Optional: UV Drying System
● Optional: Rubber Plate Mounting Machine
● Optional: UV Drying System
Model | KTFP-CI300W |
Printing Color | 8 Colors (4+4) |
Raw Material Width | 600/800/1000/1200mm (23.6”/31.5”/39.4”/47.2”) |
Printing Length (Repeat) | 300-1200mm (11.8” - 47.2”) |
Max. Mechanical Speed | 300m/min |
Max. Printing Speed | 250m/min |
Ceramic Anilox Roller | 200-800LPI |
Rubber Plate Thickness | 1.14mm /1.7mm |
Doctor Blade | Double-Side Enclosed Type |
Central Drum Diameter | Φ1200mm (47.2”) |
Color Register Precision | ±0.15mm (Vertical/ Horizontal) |
Unwind and Rewind Diameter | Φ800mm (31.5”) |
Paper Core Inner Diameter | Φ76mm (3”) |
Ink | Water Based /Solvent Based |
Tension Range | 3-50kg |
Tension Precision | ±0.3kg |
Air Supply | 0.6Mpa |
Drying Way | Electrical Heating |
Power Support | 3 Phase 220/380/440V 50/60HZ |
High Speed Flexographic Printing Machine China Flexo PP Non Woven Fabric Printing Machine Ci Flexo Printing Machine Manufacturer
