ADS1110 16 bit AD self calibrating A/D converter module voltage acquisition thermocouple temperature detection

 ADS1110 16-bit module self-calibrating A/D converter module voltage acquisition thermocouple temperature detection

The ADS1110 is A precision continuous self-calibrating mode/digital A/D converter with differential input and resolution up to 16 bits packaged for small SOT23-6 in-chip 2.048V reference voltage range of 2.048V input differential voltage, The ADS1110 operates on a single power supply from 2.7V to 5.5V using a compatible I2C serial interface. The ADS1110 can sample 15, 30, 60 or 240 times per second for conversion. The programmable gain amplifier PGA provides up to 8x gain and allows measurement of smaller signals at high resolution. In single cycle conversion mode, the ADS1110 automatically power down after one conversion, greatly reducing current consumption during idle period. The ADS1110 is designed for applications requiring high-resolution measurements where space and power consumption are primary concerns typical applications include portable instrumentation industrial process control and small transmitters.

Note:New parts and in original factory package!

Sincerely looking forward to our cooperation!
Any feedback from you would be highly appreicately!

Selling Units:

Single item

Lead Time :

Quantity(Piece)	1 - 2000	>2000
Est. Time(days)	2	To be negotiated
