Property | Test Condition | Unit | Standard | typical Value | ||
C | Melt volume-flow rate | 300 °C/ 1.2 kg | cm³/10 min | ISO 1133 | 12 | |
Melt mass-flow rate | 300 °C/ 1.2 kg | g/10 min | ISO 1133 | 13 | ||
C | Molding shrinkage, parallel | 60x60x2 mm/ 500 bar | % | ISO 294-4 | 0.7 | |
C | Molding shrinkage, normal | 60x60x2 mm/ 500 bar | % | ISO 294-4 | 0.75 | |
Molding shrinkage, parallel/normal | Value range based on general practical experience | % | b.o. ISO 2577 | 0.6-0.8 | ||
Property | Test Condition | Unit | Standard | typical Value | ||
C | Tensile modulus | 1 mm/min | MPa | ISO 527-1,-2 | 2400 | |
C | Yield stress | 50 mm/min | MPa | ISO 527-1,-2 | 66 | |
C | Yield stress | 50 mm/min | % | ISO 527-1,-2 | 6.1 | |
C | Nominal strain at break | 50 mm/min | % | ISO 527-1,-2 | >50 | |
Stress at break | 50 mm/min | kJ/m² | ISO 527-1,-2 | 70 | ||
Stress at break | 50 mm/min | kJ/m² | b.o. ISO 527-1,-2 | 120 | ||
C | Tensile creep modulus | 1 h | MPa | ISO 899-1 | 2200 | |
C | Tensile creep modulus | 1000 h | MPa | ISO 899-1 | 1900 | |
Flexural modulus | 2 mm/min | MPa | ISO 178 | 2400 | ||
Flexural strength | 2 mm/min | MPa | ISO 178 | 97 | ||
Flexural strain at flexural strength | 2 mm/min | % | ISO 178 | 7.1 | ||
Flexural stress at 3.5 % strain | 2 mm/min | MPa | ISO 178 | 73 | ||
C | Charpy impact strength | 23 °C | kJ/m² | ISO 179/1eU | N | |
Charpy impact strength | -60 °C/ | kJ/m² | ISO 179/1eU | N | ||
Charpy notched impact strength | 23 °C/3mm | kJ/m² | ISO 21305/based on ISO 180/A | 70P(C) | ||
Charpy notched impact strength | -30 °C/3mm | kJ/m² | ISO 21305/based on ISO 180/A | 16C | ||
Izod notched impact strength | 23 °C/3mm | kJ/m² | ISO 21305/based on ISO 180/A | 70P | ||
Izod notched impact strength | -30 °C/3mm | kJ/m² | ISO 21305/based on ISO 180/A | 15C | ||
C | Puncture impact properties - maximum force | 23 °C | N | ISO 6603-2 | 5400 | |
C | Puncture impact properties - maximum force | -30 °C | N | ISO 6603-2 | 6300 | |
C | Puncture energy | 23 °C | J | ISO 6603-2 | 60 | |
C | Puncture energy | -30 °C | J | ISO 6603-2 | 65 | |
Ball indentation hardness | N/mm² | ISO 2039-1 | 115 | |||
