Indoor Digital Advertising Column Sphere Led Display Screen P2 Curve Tradeshow Round Corner Soft 360 Pantalla De Wall Circular
- Category: >>>
- Supplier: Canbest Opto-Electrical Science & Technology Co. Ltd.
Share on (1601015509898):
Product Overview
Description
Warranty
Products Description
Technical Parameter
Model Name | FL1.8 | FL2 | FL2.5 | FL3 | FL4 | ||||||||||||
Pixel Pitch | 1.875 mm | 2 mm | 2.5 mm | 3.076 mm | 4 mm | ||||||||||||
Module Size (W*H) | 240*120 mm | 320*160 mm | 240*120 mm | 320*160 mm | 240*120 mm | 320*160 mm | 240*120 mm | 320*160 mm | 240*120 mm | ||||||||
Module Resolution | 128*64 dots | 172*86 dots | 120*60 dots | 160*80 dots | 96*48 dots | 128*64 dots | 80*40 dots | 104*52 dots | 60*30 dots | ||||||||
Module Material | Silicone | Silicone | Silicone | Silicone | Silicone | Silicone | Silicone | Silicone | Silicone | ||||||||
Module Net Weight | 170 g | 300 g | 170 g | 300 g | 170 g | 300 g | 170 g | 300 g | 170 g | ||||||||
LED Lamp Beads | SMD1515 | SMD1212 | SMD1515 | SMD1515 | SMD1515 | SMD1515 | SMD1515 | SMD1515 | SMD1515 | ||||||||
Brightness | 700-900 cd/m² | ||||||||||||||||
Refresh Rate | ≥3840 Hz | ||||||||||||||||
Driving Mode | 1/32 | 1/43 | 1/32 | 1/40 | 1/24 | 1/32 | 1/20 | 1/26 | 1/16 | ||||||||
Color Depth | 14 bit | ||||||||||||||||
Viewing Angle | 160°(H) / 160°(V) | ||||||||||||||||
Input Voltage | AC110V~240V±5% | ||||||||||||||||
Max. Power Consumption | 700 W/㎡ | 700 W/㎡ | 700 W/㎡ | 700 W/㎡ | 700 W/㎡ | 700 W/㎡ | 700 W/㎡ | 700 W/㎡ | 600 W/㎡ | ||||||||
Ave. Power Consumption | 215 W/㎡ | 215 W/㎡ | 215 W/㎡ | 215 W/㎡ | 215 W/㎡ | 215 W/㎡ | 215 W/㎡ | 215 W/㎡ | 215 W/㎡ | ||||||||
Working Life | ≥100,000 h | ||||||||||||||||
Protection Grade | IP20 | ||||||||||||||||
Maintenance | Front and Rear | ||||||||||||||||
