4 Color Flexographic Printing Machine Six Colour Ci Flexo Printing Machine Price Central Impression Paper Flexo Printing Press

Share on (1601017003331):


Price:$550,000.00

Quantity:


Product Overview

Description



4 Color Flexographic Printing Machine Six Colour Ci Flexo Printing Machine Price Central Impression Paper Flexo Printing Press








This Central Impression Flexo Printing Machine Is Suitable for Roll to Roll Printing Paper, Non Woven Fabric, PP Woven Fabric, And Other Similar Roll Type Materials.


Unwind and Rewind with Auto Tension Control

PLC Touch Screen Control System

Sleeves Type Printing Cylinder Loading

Use Servo Motor Drive System

With Web Video Inspection

Optional: UV Drying System

Optional: Ceramic Anilox Roller Ultrasonic Clean Machine

Double Station Shaftless Auto Loading

With Ceramic Anilox Roller

Sleeves Type Anilox Roller Loading

Double Side Enclosed Type Doctor Blade

With Auto Color Register System

Optional: Rubber Plate Mounting Machine





Model
KTFP-CIG500P
Printing Color
4/6/8 colors
Raw Material Width
1300/1500mm (51”/59”)
Printing Length (Repeat)
370-1200mm (14.6” - 47.2”)
Max. Mechanical Speed
500m/min
Max. Printing Speed
450m/min
Ceramic Anilox Roller
200-800LPI
Rubber Plate Thickness
1.14mm /1.7mm
Doctor Blade
Double-Side Enclosed Type
Color Register Precision
±0.10mm (Vertical/ Horizontal)
Unwind and Rewind Diameter
Φ1500mm (59”)
Paper Core Inner Diameter
Φ76/ Φ152mm (3”/6”)
Ink
Water Based /Solvent Based
Tension Range
3-50kg
Tension Precision
±0.3kg
Air Supply
0.6Mpa
Drying Way
Electrical Heating
Power Support
3 Phase 220/380/440V 50/60HZ






























4 Color Flexographic Printing Machine Six Colour Ci Flexo Printing Machine Price Central Impression Paper Flexo Printing Press
