10 year factory 12V 24V LiFePO4 100Ah 200Ah 300Ah Lithium Ion Phosphate Battery Pack for Solar Energy System OEM Solar battery
- Category: >>>
- Supplier: Huizhou Epever Technology Co. Ltd.Huizhou Ltd.
Share on (1601017360603):
Product Overview
Description
EPEVER 24v 100ah Lifepo4 Battery 5000 Deep Cycle BMS Lifepo4 5 Years Warranty 12v 24v 100ah 120ah 200ah
Features
A grade brand new prismatic LiFePO4 cells
LCD display screen to monitor cell SOC, voltage, temperature
and alarm status
and alarm status
≥5000 cycles @80% DOD(25℃,0.5C)
Cell balance function
Metal Case, excellent heat dissipation, more safety
Over charge, over discharge, over temperature, low temperature, over current and short circuit protection
Certificate: UN38.3, MSDS,IEC62133
Cell balance function
Metal Case, excellent heat dissipation, more safety
Over charge, over discharge, over temperature, low temperature, over current and short circuit protection
Certificate: UN38.3, MSDS,IEC62133
Easy installation and maintenance free
Max.4 battery packs can be connected in series
Max.4 battery packs can be connected in series
Model | LFP1.28KWH12.8V | LFP1.53KWH12.8V | LFP2.56KWH12.8V |
Utility Input | |||
Battery Type | LiFePO4 | LiFePO4 | LiFePO4 |
Nominal Voltage (V) | 12.8 | 12.8 | 12.8 |
Nominal Capacity (AH) | 100 | 120 | 200 |
Energy (WH) | 1280 | 1530 | 2560 |
Pack Mode | 4S1P | 4S1P | 4S2P |
Continuous Discharge Current (A) | 50 | 60 | 50 |
Charge Cut-off Voltage (V) | 14.4 | 14.4 | 14.4 |
Discharge Cut-off Voltage (V) | 10.4 | 10.4 | 10.4 |
Max.Charge Current (A) | 50 | 50 | 50 |
Max.Discharge Current (A) | 100 | 100 | 100 |
Peak Discharge Current (A) | 120@10S | 130@10S | 130@10S |
Recommend Discharge Current (A) | 50 | 60 | 50 |
Recommend Discharge Depth (％) | 80 | 80 | 80 |
Cycle Life | ≥5000 cycles (25°C, 0.5C ) 80% DOD | ≥5000 cycles (25°C, 0.5C ) 80% DOD | ≥5000 cycles (25°C, 0.5C ) 80% DOD |
Communication | — | — | — |
Display | LCD | — | LCD |
Charge&Discharge Temperature (℃) | Charge: 0°C~+55°C / Discharge: -20°C~+60°C | Charge: 0°C~+55°C / Discharge: -20°C~+60°C | Charge: 0°C~+55°C / Discharge: -20°C~+60°C |
Optimal Storage Temperature (℃) | 5℃～+35℃ | 5℃～+35℃ | 5℃～+35℃ |
Recommend Storage Humidity | 20%~80% | 20%~80% | 20%~80% |
Terminal | M8 | M8 | M8 |
Dimensions (L*W*H) (mm) | 260*180*166 | 339*185*218 | 450*180*166 |
Weight (Kg) | 12±0.5 | 19±0.5 | 22±0.5 |
Transportation | UN38.3, MSDS, IEC62133 | UN38.3 MSDS | UN38.3 MSDS |
IP Class | IP20 | IP 65 | IP20 |
Model | LFP2.56KWH25.6V | LFP3.07KWH25.6V |
Utility Input | ||
Battery Type | LiFePO4 | LiFePO4 |
Nominal Voltage (V) | 25.6 | 25.6 |
Nominal Capacity (AH) | 100 | 120 |
Energy (WH) | 2560 | 3072 |
Pack Mode | 8S1P | 8S1P |
Continuous Discharge Current (A) | 50 | 60 |
Charge Cut-off Voltage (V) | 28.8 | 28.8 |
Discharge Cut-off Voltage (V) | 20.8 | 20.8 |
Max.Charge Current (A) | 50 | 50 |
Max.Discharge Current (A) | 100 | 100 |
Peak Discharge Current (A) | 120@10S | 130@10S |
Recommend Discharge Current (A) | 50 | 60 |
Recommend Discharge Depth (％) | 80 | 80 |
Cycle Life | ≥5000 cycles (25°C, 0.5C ) 80% DOD | ≥4000 cycles (25°C, 0.5C ) 80% DOD |
Communication | — | — |
Display | LCD | — |
Charge&Discharge Temperature (℃) | Charge: 0°C~+55°C / Discharge: -20°C~+60°C | Charge: 0°C~+55°C / Discharge: -20°C~+60°C |
Optimal Storage Temperature (℃) | 5℃～+35℃ | 5℃～+35℃ |
Recommend Storage Humidity | 20%~80% | 20%~80% |
Terminal | M8 | M8 |
Dimensions (L*W*H) (mm) | 450*180*166 | 523*269*218 |
Weight (Kg) | 22±0.5 | 29±0.5 |
Transportation | UN38.3, MSDS, IEC62133 | UN38.3, MSDS, IEC62133 |
IP Class | IP20 | IP 65 |
Certifications
Company Profile
BEIJING EPSOLAR TECHNOLOGY CO.,LTD.founded in 2007, is a research, development and manufacturing enterprise focusing on photovoltaic off-grid controller, inverter, control inverter, photovoltaic energy storage inverter and photovoltaic power generation solutions.And set up a branch office in Shenzhen.
In 2019 we established subsidiary.HUIZHOU EPEVER TECHNOLOGY CO., LTD.passed ISO9001: 2015, ISO14001:2015 and ISO45001:2018.It is a cross-industry fast growing enterprise of green energy, integrating product design, research and development,production, sales and service.Manufacture solar charge controllers, off-grid inverters, inverter chargers, solar power system and other solar power units.
Our products comply with international standards CGC-SOLAR, CE, ROHS, FCC,ETL, and UL certificates.Widely used in solar power station system, communication power supply system, monitoring power supply system,off-grid hybrid power supply system, RV power supply system, street lamp power supply system and other application scenarios. It have been sold to more than 120 countries and regions around the world, and get the user's praise and recognition.
