Wall Mount Lifepo4 51.2V 48 Volt 100Ah 150Ah 200Ah 5Kwh Home Energy Storage Battery For 5Kw Off Grid Solar Power System
- Category: >>>
- Supplier: Shenzhen Qishou Technology LimitedShenzhen Limited
Share on (1601017602720):
Product Overview
Description
Product Description
* Please Click Here:We Provide OEM /ODM Serevice !
* Quick Delivery From Spot In China.
We are committed to making the safest lithium iron phosphate batteries.
All of our batteries have undergone rigorous testing and are certified safe for use in applications around the world.
All lithium batteries in our sales comply with CE, UN38.3,MSDS and other transportation regulations, quick delivery from spot!
If you need product related certificate, please contact us to send to you!
* For additional benefits For resellers we provide super price for you and policy,
We are committed to making the safest lithium iron phosphate batteries.
All of our batteries have undergone rigorous testing and are certified safe for use in applications around the world.
All lithium batteries in our sales comply with CE, UN38.3,MSDS and other transportation regulations, quick delivery from spot!
If you need product related certificate, please contact us to send to you!
* For additional benefits For resellers we provide super price for you and policy,
We offer one-stop solar energy storage solutions, please contact us directly and we will tell you more. Most importantly, we can provide you with professional solutions tailored to your local market. Low profit?
Don't worry, our engineering team will help you out
Products Description
Model | QSO-48-105A | QSO-48-184A | QSO-48-230A | QSO-48-304A |
Nominal Voltage | 51.2V | 51.2V | 51.2V | 51.2V |
Nominal Capacity | 105Ah | 184Ah | 230Ah | 304Ah |
Energy | 5376Wh | 9420Wh | 11776Wh | 15565Wh |
Series or Parallel Connection | 16S1P | 16S1P | 16S1P | 16S1P |
Dimensions (L x W x H) | 538*398*230.5mm（21.18x15.66x9.07”) | 655x555x178mm （25.78x21.85x7.01”) | 635*416*280mm (25x16.37x11.023”) | 760*500*280mm (29.92x19.68x11.02 ”) |
Net Weight | 55kg (121.25 lbs) | 55kg (176.37lbs) | 95kg (209.4 lbs) | 110kg (242.51 lbs) |
Communication Interface | RS485/CAN (Optional) | RS485/CAN (Optional) | RS232/RS485/CAN (Optional) | RS232/RS485/CAN(Optional) |
Case Material | Metal | Metal | Metal , Wheel is optional | Metal,Wheel is optional |
Enclosure Protection | IP55 | IP55 | IP54 | IP54 |
Chemistry | LiFePO4 | LiFePO4 | LiFePO4 | LiFePO4 |
Recommended Charge Current | 21A-60A | 21A-60A | 46A~100A | 60A-100A |
Maximum Charge Current | 100A | 100A | 200A | 200A |
Charge Current (-20 to -10 ºC) | ≤0.05C | ≤0.05C | ≤0.05C | ≤0.05C |
Recommended Charge Voltage | 56V-57.6V | 56V-57.6V | 56V-57.6V | 56V-57.6V |
BMS Charge Voltage Cut-Off | 57.6V (3.75±0.025vpc) | 57.6V (3.75±0.025vpc) | 57.6V (3.75±0.025vpc) | 57.6V (3.75±0.025vpc) |
Reconnect Voltage | 54.6V (3.34 ±0.05vpc) | 54.6V (3.34 ±0.05vpc) | 54.6V (3.34 ±0.05vpc) | 54.6V (3.34 ±0.05vpc) |
Company Profile
Certifications
Exhibition
FAQ
Q：How does your BMS look at battery data?
A：We can view the simple data of the battery string through the LCD screen connected with BMS, or view the detailed data of the battery string from the inverter after communicating with the inverter, or connect the computer through RS485 to USB adapter, and
view the upper computer software we provide installed on the computer.
Q：Does your BMS have current balance?
Q: How do I know whether you've shipped my order or not?
A: Tracking No. will be offered as soon as your order be shipped out. Before that, our sales will be there to check the packing status, photo you the done order and let you know the forwarder picked it up.
A：We can view the simple data of the battery string through the LCD screen connected with BMS, or view the detailed data of the battery string from the inverter after communicating with the inverter, or connect the computer through RS485 to USB adapter, and
view the upper computer software we provide installed on the computer.
Q：Does your BMS have current balance?
A：yes,We have the current passive balance function, the passive balance function module is
integrated on the BMS board, do not need external balance device.
Q: Are these battery packs compatible with my inverter?
integrated on the BMS board, do not need external balance device.
Q: Are these battery packs compatible with my inverter?
Do you have a list of companies with compatible inverters?
A: Yes, Sir. Our battery pack is compatible with most brands of inverters on the market.
A: Yes, Sir. Our battery pack is compatible with most brands of inverters on the market.
Contact us and let me tell you more.
4. Q: I need more features such as Bluetooth and LED screen,
Can I customize my battery pack?
A: Certainly. Just tell me what you need and our professional team of engineers will provide it for you An excellent solution that exceeds your expectations.
Q: How do I know whether you've shipped my order or not?
A: Tracking No. will be offered as soon as your order be shipped out. Before that, our sales will be there to check the packing status, photo you the done order and let you know the forwarder picked it up.
