Basic performance | rating | unit | Test methodology | unit |
Melt flow rate | ASTM D-1238 | g/10min | ||
15 | (Cond.L)g/10min | unit | ||
5.5 | (Cond.G)g/10min | Mpa | ||
Mechanical properties | rating | unit | Test methodology | |
Elongation | 40 | % | ASTM D-638 | D/m |
Tensile strength | 250(3550) | kg/cm(lb/in) | ASTM D-638 | unit |
IZOD Impact Strength (1/4") | 9.0(1.65) | kg.cm/cm(ft.lb/in) | ASTM D-256 | °C |
Rockwell hardness | 75 | L | ASTM D-785 | unit |
Bending elasticity | 2.0(2.8) | 10kg/cm(10lb/in) | ASTM D-790 | |
Bending strength | 380(5400) | kg/cm(lb/in) | ASTM D-790 | |
IZOD Impact Strength (1/8") | 11.0(2.02) | kg.cm/cm(ft.lb/in) | ASTM D-256 | |
Thermal performance | rating | unit | Test methodology | |
specific gravity | 1.05 | 23/23℃ | ASTM D-792 | |
Heat deflection temperature | 82(180) | ℃(°F) | ASTM D-648 | |
Vicat softening point | 98(208) | ℃(°F) | ASTM D-1525 | |
Burn rate | 1/16"HB | File No E56070 UL&C-CL |
