Brand New China City Tourism Wedding Vehicle Luxury Electric Mini Sightseeing Bus
- Category: >>>
- Supplier: Zhejiang Shanyuan New Energy Technology Co. Ltd.
Share on (1601018407268):
Product Overview
Description
Product Description
Model number | YCT23 |
Electric control | Imbor AC 72V400A |
battery | 6V200AH/ only, 12 non-dimensional batteries |
Electric machine | 7.5KW AC motor |
charger | Portable intelligent charger |
Charging time | 8-10 hours (80% discharge rate) |
Basic body color | White, green, yellow, blue (customized according to customer needs) |
Car body | Steel frame + sheet metal (FRP) shell |
tyre | Steel wheels 155R12C vacuum radial tire |
Rated occupant | eleven |
Dimensions Length * width * height | 4570*1540*2040mm |
Vehicle equipment mass | 1280kg |
Vehicle load | 935kg |
Front and rear wheel bases | 1270/1225mm |
wheelbase | 2650mm |
Minimum turning radius | 6m |
Minimum ground clearance | 150mm |
Braking distance | ≤5m |
Charge input voltage | 220v |
Maximum travel speed | ≤30km/h |
Driving range | 110-120km |
Maximum gradient | 0.1 |
Product Display
Please Consult For More Product Details.
