American ESS Split Phase High Voltage 85~400V Hybrid Commerce Industry Inverter
- Category: >>>
- Supplier: Xiamen Sweet Power Tech. Co. Ltd.
Share on (1601018804310):
Product Overview
Description
American ESS Split Phase inverter (battery voltage>80V)
Product Features: Flexible configuration: Support full power charge and discharge, better charge and discharge efficiency Support 100% unbalanced load capacity
Safe and reliable: Passed UL 1741:2021, IEEE 1547.1, UL1699B test certification Support multi-machine parallel mode sharing a battery pack
Advanced: Home smart energy management system of Split Phase Solar Inverter Support power dispatch and demand response management Equipped with CAN port, RS485 port, RS232 port for remote control, DRM port, which makes the system smart and flexible.
Intelligent & Friendly: Customizable I / O interface, more flexible application Support remote monitoring, remote upgrade and automatic battery management
|
| Model | SIXP6KHE | SIXP8KHE | SIXP10KHE | SIXP12KHE |
| Input(PV) | ||||
| Max.input power(kW) | 7.8KW | 10.4KW | 13KW | 15.6KW |
| Max. DC voltage(V) | 500V | |||
| MPPT voltage range(V) | 120~500V | |||
| Max.input current of single MPPT(A) | 12A | |||
| MPPT tracker/strings | 4/1 | |||
| AC output | ||||
| Rated output power(KVA) | 6KVA | 8KVA | 10KVA | 12KVA |
| Max output current(A) | 27.3A | 36.4A | 45.4A | 50A |
| Grid voltage/range(V) | 240/211~264V | |||
| Frequency (HZ) | 50/60Hz | |||
| PF | 0.8lagging-0.8leading | |||
| THDI | <3% | |||
| Type of grid connection | L+N+PE | |||
| EPS output | ||||
| Rated power (KVA) | 6KVA | 8KVA | 10KVA | 12KVA |
| Rated output voltage(V) | 220-240/110-120 | |||
| Rated frequency (HZ) | 50/60Hz | |||
| Automatic switching time (MS) | <20ms | |||
| THDU | <2% | |||
| Overload capacity | 110%,30S/120%,10S/150%,0.02S | |||
| Battery | ||||
| Battery voltage range(V) | 85V~400V | |||
| Max. charging voltage(V) | 400V | |||
| Full battery voltage(V) | 85V | 110V | 140V | 160V |
| Rated charge/discharge current(A) | 80/80A | |||
| Battery type | Lithium /Lead-acid | |||
| Communication interface | CAN/RS485 | |||
| General data | ||||
| Max. efficiency | ≥98.2% | |||
| CEC efficiency | ≥97.2% | |||
| Ingress protection | IP65/NEMA 3R | |||
| Noise emission (DB) | <25db | <25db | <29db | <29db |
| Operation temperature | -25~+60℃ | |||
| Cooling | Natural | |||
| Relative humidity | 0~95%(non-condensing) | |||
| Altitude | 2,000m(>2,000 Derating) | |||
| Weight (KG) | 32KG | |||
| Dimensions W*D*H(MM) | 530*200*660mm | |||
| Display and communication | ||||
| Display | LCD | |||
| Interface:RS485/WiFi/4G/CAN/DRM | Yes/ Opt/ Opt/ Yes/ Yes | |||
| standby power consumption at night (W) | <2.5W(With the battery<5W) | |||
| Isolation transfomer | Yes | |||
| Safety standard | UL1741SA all options, UL1699B, CSA 22.2 | |||
| EMC | FCC Part 15, Class B | |||
| On-grid | IEEE 1547,IEEE 2030.5, Hawaii Rule 14H, Rule 21 Phase I, II, III | |||
