Product Overview
Description
Products Description
* The chassis supports EEB (12" x 13") motherboard installations up to the maximum
* Supports 16 3.5" (or 2.5") hot-swappable hard disk slots, four 4.2" non-hot-swappable hard disk slots as standard, and two 5.2" hot-swappable hard disk slots at the rear
* The chassis backplane supports 12Gb/s transmission speed and adopts high-quality FR4 high-speed plate
* The chassis backplane supports the SGPIO function, which provides a visual indication of the working status of the hard drive
* Support intelligent temperature control, which solves the noise and heat dissipation of the chassis
* Three 3 hot-swappable fans are used
* This chassis supports fan shockproof, which solves the problem of reducing the transmission speed and life of the hard disk due to chassis vibration
* Support single power or 1+1 redundant electricity
* Supports 7 full-height PCIe expansion card slots
* The chassis accommodates standard 19-inch cabinet mounting
* Suitable for HPC, WEB, database, file server and storage server
* Supports 16 3.5" (or 2.5") hot-swappable hard disk slots, four 4.2" non-hot-swappable hard disk slots as standard, and two 5.2" hot-swappable hard disk slots at the rear
* The chassis backplane supports 12Gb/s transmission speed and adopts high-quality FR4 high-speed plate
* The chassis backplane supports the SGPIO function, which provides a visual indication of the working status of the hard drive
* Support intelligent temperature control, which solves the noise and heat dissipation of the chassis
* Three 3 hot-swappable fans are used
* This chassis supports fan shockproof, which solves the problem of reducing the transmission speed and life of the hard disk due to chassis vibration
* Support single power or 1+1 redundant electricity
* Supports 7 full-height PCIe expansion card slots
* The chassis accommodates standard 19-inch cabinet mounting
* Suitable for HPC, WEB, database, file server and storage server
Specification
Chassis form | Rack-mounted |
Chassis height | 3U |
Adapts to the motherboard | EEB(12*13)/CEB(12*10.5)/ATX(12*9.5)/Micro ATX |
Power supply type | Single electricity or 1+1 redundant electricity |
Backplane | 12Gb/s direct attach to the backplane |
Disk bits | Support SGPIO, compatible with SAS 3.0/SATA3.0 hard disks, 16 3.5" (or 2.5") hot-swappable hard disk slots, standard 4 2.5" non-hot-swappable hard disk slots, optional 2 rear 2.5" hot-swappable hard disk slots |
Hard drives are shockproof | The hard disk rack adopts EMI shrapnel design and unique shockproof fan design, which reduces the resonance between the fan and the hard disk and does not affect the hard disk I/O speed |
System fan | Support intelligent temperature control, standard 3 12038 hot-swappable fans |
Expansion card slots | 7 full-height PCIe expansion card slots |
security | Lock screw cover |
Front plate control | 2 x USB2.0, 1 x On, 1 x Reboot button, 1 x HDD LED, 1 x System Fault LED, 2 x Network LED |
Slide | Matching |
Wind shroud | Matching |
Front cover | Matching |
Product material | Imported SGCC (galvanized steel sheet) ABS panel and punched mesh |
Chassis dimensions | 670*444*132mm(D*W*H) |
Chassis gross weight | 15.5kg(net) / 21.5kg(gross) |
Package size | 902*591*273mm(D*W*H) |
