High Pressure DC 3 12V Long Lifespan Mini Diaphragm Pump Micro Air Pump

Share on (1601019462994):


Price:$1.99 - $2.50

Quantity:


Product Overview

Description



Product Description


Micro Air Pumps
An air pump is a pump for pushing air. Examples include a bicycle pump, pumps that are used to aerate an aquarium or a pond via an airstone; a gas compressor used to power a pneumatic tool, air horn or pipe organ; a bellows used to encourage a fire; a vacuum cleaner and a vacuum pump. All air pumps contain a part that moves (vane, piston, impeller, diaphragm etc.) which drives the flow of air. When the air gets moved, an area of low pressure gets created which fills up with more air.

Mini air pumps are widely used for applications that requires use pump with small volume, low power consumption, low noise and low price. Such as fish tank, sphygmomanometer, Inflation Pump, Biofuel Industry, Food and Beverage Industry, Industrial Utilities, Home Application, Medical Equipment etc.


Wuhan Yeson Technologies has been engaged in manufacturing miniature water/air/vacuum and peristaltic pumps for many years, we have any standard models with affordable price in stock and we can also custom as per your unique requirements. Please kindly reach out, we'll come back to you with satisfied solution.


Specification




SPECIFICATIONS




Rated Voltage
DC 3V
DC 6V
DC 9V
DC 12V
Rated Current
≤ 800 mA
≤ 400 mA
≤ 250 mA
≤ 200 mA
Power
1-3.6 w



Flow
0.3-1.5 LPM
Pressure
≥ 50 Kpa
Noise Level
≤ 65 dB (measured 30cm away)
Lifespan
≥ 30000 times (on 10s, off 5s)
Working enviroments
0-50℃, 75% RH
Leakage
≤ 3 mmHg/min (from 300 mmHg in a 500cc tank)


Product Usage


sphygmomanometer
Vacuum packaging machine
Breast Pump


Soap Dispenser
Electric Inflation Pump
Fish Tank


Aroma Diffuser
Intelligent Closestool
Sprayer


Company Profile




Wuhan Yeson Technologies Co., Ltd. was established in Wuhan, China in 2019. We are a company specializing in R&D, manufacturing and sales of micro diaphragm pumps and peristaltic pumps. Our main products include micro liquid pumps, vacuum pumps, air pumps and peristaltic pumps. The factory area is about 1,000 square meters, with a total number of employees of more than 20. We now have 5 complete production lines, and the annual production capacity has now reached 3,000,000 pieces. Although the past three years have been very difficult, we have worked hand in hand with our customers to overcome difficulties and have accumulated rich experience while expanding our global market.

Wuhan Yeson Technologies has a complete research and development, production and testing technology system. We can provide customized micro pumps based on our customers' unique needs. Our products are widely used in water flosser, ear cleaners, nasal washers, aromatherapy machines, disinfection guns, oxygen injectors, blood pressure monitors, coffee machines, automatic soap dispensers, vacuum sealing machines, beauty equipment and instruments, and healthcare, environmental analysis, water treatment, laboratory analysis and testing instruments and other fields. All products will undergo strict testing prior to shipment. We believe you will be attracted by our affordable price at first and then be convinced by our high quality and after-sales service.

Looking forward to contributing to your projects with affordable prices and high quality micro pumps and expanding the market with you together.







Packing&Shipping




There are 40 pcs of pumps in every tray and each box can contain 7 trays. With that saying, one carton box can contain 40*7=280 pcs. Therefore we suggest start with 280 pieces.


t




FAQ


1. What can we do for you?
We have been manufacturing various kinds of micro diaphragm pumps with high performance and affordable price. Like micro air pump, micro vacuum pump, micro water pump and micro water & air pump.

2. How can I choose the most suitable pump?
Please tell me your detailed flow rate, voltage, application and so on, then we can recommend the most suitable pump for you.

3. How can we guarantee quality?
We have a perfect quality control team and inspect the products prior to shipment

4. How long is the delivery time?
Mass production typically takes 25 working days. For sample order, we can arrange fast dispatch in 3 working days.

5. Which shipping way is available?
DHL, FedEx, UPS, EMS, Sea are available.
For samples and packages less than 100kg, we usually suggest express shipping. For heavy packages, we suggest air shipping or sea shipping. But it all depends on our customers' needs.

6. What is your terms of Payments?
Alibaba Trade Assurance. Any trade disputes, Alibaba will guarantee your money and compensate all of your loss.
Mass production: 50% deposit, and 50% balance prior to the delivery upon inspection reports.

7. Is it OK to print my logo on this product?
Sure, please kindly check with us before we start the production.

8. What's your warranty?
The warranty is 1 year. We typically deliver new and faultless products. Also, we can replace the defective ones in the warranty period, meanwhile we provide life-long free technical support and maintenance.
