Product Overview

Description









TZQM air box pulse bag dust collector is a new and efficient bag dust collector independently researched and developed by our company on the basis of digesting and absorbing foreign advanced technology and in combination with our national conditions. It integrates the advantages of chamber back blowing and jet pulse bag dust collector, overcomes the shortage of kinetic energy of chamber back blowing for cleaning dust, and the defects of secondary adsorption of dust caused by simultaneous dust clean and filtering of jet pulse. It adopts efficient off-line dust removal mode, which has the characteristics of large dust removal capacity, good dust removal effect, low system resistance, long service life of filter bag, high dust removal efficiency, etc. It is widely used for dust purification in building materials, metallurgy, electric power, chemical industry and other industries.

This series of dust collector consists of different rooms and different filter bags in each room, forming a variety of different specifications. The number of filter bags in each room has 4 choices: 32, 64, 96 and 128, and the diameter of filter bags is Φ130mm, filter bag length is 2450mm and 3060mm.




Model
TZQM32-3
TZQM32-4
TZQM32-5
TZQM32-6
Air volume(m3/h)
6690
8930
11160
13390
Total filter area(m2)
93
124
155
186
Qty of chamber(pcs)
3
4
5
6
Bag QTY of each chamber (pcs)
32
Total QTY of filter bags (pcs)
96
128
160
192
Qty of pulse valve (pcs)
3
4
5
6
Model of filter bag(D*L mm)
φ130*2450
Filter materials
According to the using condition
Filter air speed(m/min)
0.8-2.0(choose different speed according to different processing flow )
Negative pressure(Pa)
≤6000
Resistance(Pa)
1470-1770
Inlet dust concertration(g/Nm3)
≤200
Blowing pressure(Mpa)
0.5-0.7
Compressed air consumption(Nm3/min)
0.27
0.37
0.46
0.55
Air-locking device
according to using condition
Screw conveyor
no
Heat Insulation area(M2)
26.5
34
41
48.5


Performance characteristics
1. Offline pulse dust-cleaning, with dust cleaning efficiency up to 99.9% and no secondary adsorption of dust, is especially suitable for handling high concentration flue gas.
2. High temperature flue gas is used for back blowing to effectively prevent bag sticking.
3. The use of new easy to clean filter materials and the reliable tracking system of the flue gas temperature can adapt to various flue gas conditions.
4. Fully automatic computer control, easy to operation and good reliability.
5. The air box structure reduces the local resistance loss and eliminates the inconvenience of filter bag installation.
