Kaishan 200m 300m 600m Truck Mounted Water Well Drilling Rig Machine Price With 3 Years Warranty
- Category: >>>
- Supplier: Xinxiang Toenter Technology Development Co. Ltd.
Share on (1601020152220):
Product Overview
Description
Product Description
The water well drilling rig has high working efficiency and simple and convenient operation. It only needs 3-5 people to start the work, including one operator, two small workers, one driver, one cabinet or security officer. At the same time, this equipment is widely used in water well operation, rock hole leading operation, house foundation operation, photovoltaic base station construction, wind power hydropower station foundation operation, geophysical drilling operation, etc. The quality of water well drilling rig is excellent, and there are many models for you to choose from.
Video display
Specification
The weight（T） | 5.5 | Drill pipe diameter（mm） | Φ76/Φ89 | ||
The hole diameter（mm） | 140-254 | Drill pipe length（m） | 1.5m/2.0m/3.0m | ||
Drilling depth（m） | 200 | Rig lifting force（T） | 13 | ||
One-time advance length（m） | 3.3 | Rapid rise speed（m/min） | 30 | ||
Walking speed（km/h） | 2.5 | Fast feeding speed（m/min） | 60 | ||
Climbing angles（Max.） | 30 | Width of loading（m） | 2.4 | ||
Equipped capacitor（kw） | 65 | Hoisting force of winch（T） | 1.5 | ||
Using air pressure（MPA） | 1.7-2.5 | Swing torque（N.m） | 3400-4700 | ||
Air consumption（m³/min） | 17-31 | Dimension（mm） | 4000×1750×2250 | ||
Swing speed（rpm） | 45-70 | Equipped with hammer | Medium and high wind pressure series | ||
The penetration efficiency（m/h） | 10-35 | High leg stroke（m） | 1.4 | ||
The engine brand | Quanchai engine | ||||
