Factory supplier industrial large ultrasonic welding machine hot melt welding machine for plastic
- Category: >>>
- Supplier: Xianyang Chic Machinery Co. Ltd.Xianyang Ltd.
Share on (1601020370157):
Product Overview
Description
Large ultrasonic welding machine
When the ultrasonic wave acts on the thermoplastic plastic contact surface, it will produce tens of thousands of times of
high-frequency vibration per second. This high-frequency vibration reaches a certain amplitude, and the ultrasonic energy is
transmitted to the welding area through the welding horn. Because the acoustic resistance of the welding area is large, the local
high temperature will be generated. And because of the poor thermal conductivity of the plastic, it cannot be distributed in time
and gathered in the welding area, which causes the contact surface of the two plastics to melt rapidly. After adding a certain
pressure, it will be fused into one. When the ultrasonic stops, let the pressure continue for a while to hold the pressure to make
it solidify and shape, so that a solid molecular chain is formed to achieve the purpose of welding, and the welding strength can
be close to the strength of the raw material.
Feature:
Use high-power iron shell transistor, strong output, strong stability with full color fast response, 4 core 32-bit processor, and
485 communication, Chinese, English and other languages. It has customized real-time frequency automatic tracking overload,
transducer voltage protection. It has easily automatic control 30-125mm stroke cylinder interchangeable. According to the product
flexible strain mold impedance analysis, overload, and transducer voltage protection. Full body CNC machining, heavy casting
process, strong steel, more precise digital operation, simple operation, intelligent protection. Effectively reduce mold,
transducer loss. Time, energy, power, external control mode. Meet the diversified welding needs. Control mode: non-standard, safe,
fast, continuous vibration. Welding amplitude 10%-100% can be adjustable (1% accuracy) amplitude compensation. Trapezoidal screw
and trapezoidal nut match, with automatic lock function. The head is not gravity automatic slide precision umbrella teeth and
plane bearing match, lifting smoothly, labor saving, stable and no shaking four-point balance fine-tuning level. High precision
adjustment level international first-line brand quality accessories, weld more precise, stable hands start, front with emergency
brake button, can be used to control the external switch. Lower storage space design, can be placed electric box, mold, tool box,
etc. The ultrasonic machine can be installed with grating, sound enclosure, operation safety in line with international standards
CF\\FCC certification.
When the ultrasonic wave acts on the thermoplastic plastic contact surface, it will produce tens of thousands of times of
high-frequency vibration per second. This high-frequency vibration reaches a certain amplitude, and the ultrasonic energy is
transmitted to the welding area through the welding horn. Because the acoustic resistance of the welding area is large, the local
high temperature will be generated. And because of the poor thermal conductivity of the plastic, it cannot be distributed in time
and gathered in the welding area, which causes the contact surface of the two plastics to melt rapidly. After adding a certain
pressure, it will be fused into one. When the ultrasonic stops, let the pressure continue for a while to hold the pressure to make
it solidify and shape, so that a solid molecular chain is formed to achieve the purpose of welding, and the welding strength can
be close to the strength of the raw material.
Feature:
Use high-power iron shell transistor, strong output, strong stability with full color fast response, 4 core 32-bit processor, and
485 communication, Chinese, English and other languages. It has customized real-time frequency automatic tracking overload,
transducer voltage protection. It has easily automatic control 30-125mm stroke cylinder interchangeable. According to the product
flexible strain mold impedance analysis, overload, and transducer voltage protection. Full body CNC machining, heavy casting
process, strong steel, more precise digital operation, simple operation, intelligent protection. Effectively reduce mold,
transducer loss. Time, energy, power, external control mode. Meet the diversified welding needs. Control mode: non-standard, safe,
fast, continuous vibration. Welding amplitude 10%-100% can be adjustable (1% accuracy) amplitude compensation. Trapezoidal screw
and trapezoidal nut match, with automatic lock function. The head is not gravity automatic slide precision umbrella teeth and
plane bearing match, lifting smoothly, labor saving, stable and no shaking four-point balance fine-tuning level. High precision
adjustment level international first-line brand quality accessories, weld more precise, stable hands start, front with emergency
brake button, can be used to control the external switch. Lower storage space design, can be placed electric box, mold, tool box,
etc. The ultrasonic machine can be installed with grating, sound enclosure, operation safety in line with international standards
CF\\FCC certification.
Machine table | 920 * 780 * 1850 mm |
Service voltage | 220 V |
Working production | 8-15 times/min |
weight | 180 kg |
Welding area | plane 500 mm |
Welding head stroke | 100 MM |
The touch screen is convenient and intelligent. Tight time control, up to 0.01 seconds.
Automatic protection circuit when welding abnormality and energy overload occur.
Use 7075 alloy aluminum material, good sonic conductivity, no heating, no cracking, long service life.
Applicable welding materials:
Applicable to ABS, PC, PE, PP, PS, PVC, SAM, acrylic, cellulose, nylon, metal etc.
Scope of application
Widely used in automotive industry, electronic industry, medical industry, household appliances industry, below with mold/horn and
samples for reference.
Applicable to ABS, PC, PE, PP, PS, PVC, SAM, acrylic, cellulose, nylon, metal etc.
Scope of application
Widely used in automotive industry, electronic industry, medical industry, household appliances industry, below with mold/horn and
samples for reference.
Q1: How to find a Packing machine suitable for my product?
Tell us about your product details and packing requirements.
1. What kind of product you would like to pack?
2. The bag / sachet / pouch size of your need for the product packing (the length and width).
3. The weight of each pack you need.
4. You requirement for the machines and the bag style.
Q2: Is engineer available to serve oversea?
Yes, but the travel fee is responsible by you. In order to save your cost, we will send you a video of full details of machine
installation and assist you till the end.
Q3. How can we make sure about the machine quality after placing the order?
Before delivery, we will send you the pictures and videos for you to check the machine quality. And also you can arrange for
quality checking by yourself or by your contacts in China.
Q4. We are afraid you won't send us the machine after we send you the money?
We have our business license and certificate. And also it is available for us to use Alibaba Trade assurance service to guarantee
your money, machine quality and make sure the machine is delivered on-time.
Q5. Can you explain me the whole transaction process?
1. Sign the Contact.
2. Arrange 30% deposit to our factory.
3. Factory arrange production.
4. Testing & detecting the machine before shipping.
5. Machine will be inspected by customer or third agency through online or site test.
6. Arrange the balance payment before shipment.
Q6: Will you provide the delivery service?
Yes. Please inform us of your final destination and we will check with our shipping agency to quote the shipping cost for your
reference before delivery.
A: Yes. Please inform us of your final destination. We will check with our shipping agency to quote the shipping cost for your
reference before delivery.
Tell us about your product details and packing requirements.
1. What kind of product you would like to pack?
2. The bag / sachet / pouch size of your need for the product packing (the length and width).
3. The weight of each pack you need.
4. You requirement for the machines and the bag style.
Q2: Is engineer available to serve oversea?
Yes, but the travel fee is responsible by you. In order to save your cost, we will send you a video of full details of machine
installation and assist you till the end.
Q3. How can we make sure about the machine quality after placing the order?
Before delivery, we will send you the pictures and videos for you to check the machine quality. And also you can arrange for
quality checking by yourself or by your contacts in China.
Q4. We are afraid you won't send us the machine after we send you the money?
We have our business license and certificate. And also it is available for us to use Alibaba Trade assurance service to guarantee
your money, machine quality and make sure the machine is delivered on-time.
Q5. Can you explain me the whole transaction process?
1. Sign the Contact.
2. Arrange 30% deposit to our factory.
3. Factory arrange production.
4. Testing & detecting the machine before shipping.
5. Machine will be inspected by customer or third agency through online or site test.
6. Arrange the balance payment before shipment.
Q6: Will you provide the delivery service?
Yes. Please inform us of your final destination and we will check with our shipping agency to quote the shipping cost for your
reference before delivery.
A: Yes. Please inform us of your final destination. We will check with our shipping agency to quote the shipping cost for your
reference before delivery.
