OEM 3KVA outdoor uninterruptible power supply with lithium battery high frequency online UPS suitable for outdoor facilities
- Category: >>>
- Supplier: Shenzhen Zhongguanda Technology Co. Ltd.
Share on (1601022264436):
Product Overview
Description
Product Description
Specification
Model | HWU1101K(1KVA) | HWU1102K(2KVA) | HWU1103K(3KVA) | |||||||
Capacity | 1KVA/0.8KW | 2KVA/1.6KW | 3KVA/2.4KW | |||||||
Nominal Voltage | 220/230/240VAC | |||||||||
Frequency | 50Hz/60Hz | |||||||||
Input | ||||||||||
Voltage Range | 115-295VAC(士3VAC) | |||||||||
Frequency Range | 50Hz(46-54 Hz);60Hz(56-64 Hz) | |||||||||
Soft Start | 0-100%5sec | |||||||||
Power Factor | 0.98 | |||||||||
Output | ||||||||||
Voltage Precision | 220/230/240VACX(1士2%)VAC | |||||||||
Frequency Precision | 50Hz/60Hz士0.05Hz | |||||||||
Power Factor | 0.8/0.9 (opional),standard 0.8 | |||||||||
Wave Distortion | Linear load <3%,Non-linear load <6% | |||||||||
Overload Capability | Overload (110%~150%)for 30 seconds,automatically transfer to bypass. When the load is back to normal,it can automatically transfer to online mode | |||||||||
Crest Factor | 3:1 | |||||||||
Transfer Time | 0 ms(AC to DC) | |||||||||
DC Supply Voltage | 48VDC | 48VDC | 48VDC | |||||||
Charging Current | 4A/8A (optional) | 4A/8A(optional) | 4A/8A(optional) | |||||||
Battery | ||||||||||
Internal Battery Capacity | LifePo4 battery pack 48VDC 50AH or 48VDC 100AH | |||||||||
Panel Display | ||||||||||
LCD | Load level,Battery level,Battery indicator,Utility power,Inverter,Bypass,Overload,Fault | |||||||||
Communications | ||||||||||
Communicate Interface | RS232,SNMP card (optional) | |||||||||
Work Environment | ||||||||||
Temperature | -40 °℃~55 ℃ | |||||||||
Humidity | 0-95%(Non-condensing) | |||||||||
Storage Temperature | -25 ℃~55 ℃ | |||||||||
Elevation | <1500m | |||||||||
Physical Characteristics | ||||||||||
Net Weight (without battery) | 85KG | 85KG | 85KG | |||||||
Dimensions:(WxDxH)mm | 542*332*626 | 542*332*626 | 542*332*626 | |||||||
