Hd Round Circular Monitor Display 23.6inch Android Round LCD advertising Display WiFi Round Digital Signage
- Category: >>>
- Supplier: Shanghai Betvis Information Technology Co. Ltd.
Share on (1601023340854):
Product Overview
Description
Introduction
Main Features
Supports capacitive and other touch screen inputs
Remote management with one- click publishing
Adopts Rexchip RK3288 chip, the system platform is based on Android 4.4 or above version
Stock and Delivery
Hot sale and ready stock with quick delivery
Design Drawing
Data Sheet
MODEL | BV-R2411 | ||
Display | Size | 23.6 inch | |
Diagonal Length | 599*681mm | ||
Resolution | 1280x1280 | ||
Display Area | 599.42mm (H) x599.42mm (V) | ||
Backlight | LED | ||
Brightness | 700cd/m2 | ||
Display colors | 16.7M , 72% NTSC | ||
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | ||
Contrast Ratio | 1000:1 | ||
Response Time | 16ms | ||
Android Solution | CPU | Rockchip RK3288, Quad-Core Cortex-A17 at 1.8G | |
Running memory | 2G DDR3 | ||
Storage | 16G FLASH | ||
Decode Resolution | Support up to 1080P | ||
Interface | SD*1,RJ45*1,HDMI OUT*1,USB*2,LVDS*1 | ||
Language | Support Chinese and English | ||
Monitor Solution | I/O | HDMI-in*1, USB*1, SD card slot*1 | |
Play Mode | Loop display of video / image/ image + audio | ||
Support Media | Video, Image, Audio | ||
FILE FORMAT | Video | RMVB，FLV，MPEG1/2/4，AVI，DIVX，XDIV，WMV9，H.264，VC-1， MOV，MKV， MP4，TS，M2T，VOB | |
Picture | BMP/PNG/GIF/JPEG | ||
Music | MP3，WMA，WAV，EAAC+， MP2 dec，Vorbis(Ogg)，AC3，FLAC，APE，BSAC； | ||
Others | Speaker | 2*5W (8Ω) | |
Package Size | 850*850*130mm | ||
Net weight | 14KG | ||
Gross weight | 16KG | ||
Other | Installation | Vertical | |
Product Size | 609.25*1700*60mm | ||
Colour | Black | ||
Gross Weight | 25KG | ||
Application
More Products
FAQ
1. Does the product accept customization?
Yes, it accepts all kinds of customization.
2. Does the product have a MOQ?
No, it doesn't. But you can get a better price when you order more.
3. What kind of after-sales service do you offer?
We offer one year warranty and lifetime technical support.
