| Parameters: |
Characteristics | Description |
Size | 120mm*70mm*50mm |
Voltage | DC9-36V, applicable to 12V/24V vehicles |
Battery | Polymer lithium battery,Capacity 3.7V/5200mAH; |
Working current | Average current <100mA@12V; |
Sleep current | <15mA@12V |
Recharge | Built-in Battery and support quick charge |
Cellular | Working frequency: • Cat M1: LTE-FDD B1/B2/B3/B4/B5/B8/B12/B13/B14/B18/B19/B20/B25/B26*/B27/B28/B66/B85 • Cat NB2: LTE-FDD B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26*/B28/B66/B71/B85 • EGPRS: 850/900/1800/1900MHz protocol: Embedded TCP/IP stack Sensitivity: -107dBm@850/900MHz -106dBm@1800/1900MHz Output power: Class 4 (2W)@850/900MHz Class 1 (1W)@1800/1900MHz GPRS data: GPRS Class 10, Mobile Station Class B |
GPS | Support GPS, AGPS and LBS |
Antenna type | Built in Cellular ,GPS antenna, |
I/O interface | 2 inputs, 1 output |
AD interface | 2 ADC inputs, input voltage 0-5V |
UART | 2 RS232 and 1 RS485 interface |
LED Indicator | Cellular, GPS, battery |
Remote upgrade(FOTA) | Support remote configuration and firmware upgrade |
Multiple IP | Support multiple IPs connecting at same time |
Dimension | 120mm*70mm*50mm |
Environment | Working temperature:-20℃~70℃; Storage temperature:-40℃~+85℃; |
IP rating | IP68 |


Q1.Can you help for design?
A:Yes,we have our own software and hardware engineer,you can give your idea to us,we can assist the design work.Provide sample for your reference.
