High Efficiency Oil Free 250 Bar Industrial Compressors Automation Piston Reciprocating N2 Nitrogen Air Compressor
- Category: >>>
- Supplier: Bengbu Aot Compressor Co. Ltd.
Share on (1601025894906):
Product Overview
Description
Product Description
The compressor adopts oil-free lubrication structure and can run continuously for a long time. Meet the process requirements, suitable for all kinds of gases. All oil-free lubrication compressors with various parameters and requirements can be customized according to customer requirements.
Main Industry: compression equipment
Various types of gas compressor: ammonia compressor/oxygen compressor/hydrogen compressor/hydrogen chloride gas compressor/compressor/freon compressor/nitrogen compressor/co2 compressor/methane compressor/liquefied petroleum gas compressor/propylene compressor/gas compressor/mixture compressor/BOG compressor/raw material gas compressor
Details Images
Scope of business: compressor and accessories production and sales;Compressor maintenance and technical service;Processing and sales of mechanical equipment and parts;Import and export business of goods and technology.
Technical Parameters
Compressor | Product Model | Industrial Compressor | |||
Type | Z Type | ||||
Compressed medium | Nitrogen | ||||
Nominal volume flow(m³/mim) | 0.28 | ||||
Compression stage | 1 | ||||
Cylinder number | 2 | ||||
Driving mode | Belt | ||||
Noise (sound pressure level) dB(A) | ≤65 | ||||
Cooling mode | Water cooling | ||||
Rotational speed (r/min) | 500 | ||||
Suction pressure (MPa G) | 0.9 | ||||
Discharge Pressure (MPa G) | 2 | ||||
Suction temperature (℃) | 40 | ||||
Discharge temperature (℃) | ≤120 | ||||
Lubrication type | Crankshaft, connecting rod, cross head | Oil lubrication | |||
Cylinder, Packing | Oil-free lubrication | ||||
Motor | Model | YB3-132M-4 | |||
Explosion-proof grade | DIIBT4 | ||||
Rotational speed (r/min) | 1450 | ||||
Rated voltage (V) | 380 | ||||
Rated frequency(Hz) | 50 | ||||
Rated current (A) | 15.4 | ||||
Rated power (Kw) | 7.5 | ||||
Compressor size (L×W×H) mm | ≈1200×1000×1000 | ||||
Weight(kg) | ≈550 | ||||
Note:With the parameters of the logo will be subject to leave the factory
Scope of supply
No. | Name | Number | Note |
1 | Compressor host | 1 | / |
2 | Explosion-proof motor | 1 | / |
3 | Gas-liquid separator | 1 | / |
4 | Gas storage tank | 1 | / |
5 | Shared chassis | 1 | / |
6 | Belt | 1 set | / |
7 | Piping components | 1 set | / |
8 | Random spare parts | 1 set | / |
9 | The technical documentation | 1 set | / |
10 | Explosion-proof control cabinet | 1set | / |
Quality Comparison | AOT Compressor Products | Other products in the same industry | ||
Material | 1The main material of the compressor is made of high-wear-resistant cast iron with Hanmill casting technology. It has high strength, good shock resistance and high wear resistance.。 2、The compressor needs a hardening treatment process for the wear-resistant part. Such as ion nitriding, laser hard quenching, surface cermet treatment, etc. 3、The rich experience can select the best suitable material for different compressors to meet the stable operation of the compressor. | Ordinary cast iron, the appearance of the surface is poor, the inner cavity is sand, which aggravates the wear and is not easy to maintain, but the price is cheap. The parts and materials are not processed or processed. No matter what kind of compressor is a model material, there is no choice, and the operation stability of the compressor cannot be guaranteed | ||
Configuration | All the matching kits are equipped with brand products, which is more secure for the whole compressor operation. | Low quality accessories，The principle is，No matter the quality is good or bad, choose whichever is cheaper. Or use fakes to impersonate. | ||
Technology | The company's independent research and development, technology continues to innovate, master the core technology. Advanced technology, exquisite workmanship, safe and durable | Counterfeit mode，Outdated products, without their own core technology, poor product stability, easy to cause gas leakage and affect safety. | ||
Produce | The company owns a physical factory，Modern high-precision processing equipment and testing facilities. Ensure that the processing accuracy of key parts of the parts is less than 1 wire. The total test time of each compressor is guaranteed to be 8 hours before leaving the factory. The total test time of some models exceeds 24 hours before leaving the factory. The whole machine test data is 100% not exceeded, and the test data is fully informationized and permanently stored. | Direct assembly by buying some cheap accessories，20 minutes after start-up, direct paint delivery。Or they are an assembly factory, there is no processing equipment at all, and some mechanical processing departments are found outside. The old equipment has poor processing precision and the quality is not guaranteed. There is no quality control measures. Most of these peers are doing OEM work for leather bags companies. | ||
Advantages of AOT compressor: 1.We win with high quality 1)With perfect quality system management, quality assurance Aot compressor has passed ISO9001:2015 quality management system certification. 2)100% inspection of sophisticated test equipment。Strive to be "100 points high quality compressor" 3)Only with quality can we have market and go further，Quality management philosophy of surviving on quality. 2.Professional production technology management ability 1)Pay attention to process quality control, important performance testing and visual inspection in all aspects of the production process. The quality is checked. 2)Full participation, strengthening management, excellence, and casting quality. 3.Have a professional technical and after-sales service team 1) Provide professional technical support and analysis for customers, Follow up before and after the order. 2) Level by level Professional after-sales customer service personnel and online staffing. | ||||
Our Company
Certifications
Why Choose Us
Packing & Delivery
FAQ
Q1: Why choose us?
A: Bengbu AOT Compressor Co., Ltd., is specialized in Special Gas Compressor. We warmly welcome your small trial order for quality or market test.
Q2: Are you a manufacturer or trading company?
A: We are professional manufacturer with big modern factory in Anhui, China. Both OEM & ODM service can be accepted.
Q3: What's your delivery time?
A: Generally 30 to 60 days, if urgently order, please contact our sales in advance.
Q4: How long is your air compressor warranty?
A: One year for the whole machine and two years for screw air end, except spare parts.
Q5: How long could your air compressor be used?
A: Generally, more than 15 years.
Q6: What's payment term?
A: T/T, L/C, Western Union, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.
Q7: How about your customer service?
A: 24 hours online service available. 48hours problem solved promise.
A: Bengbu AOT Compressor Co., Ltd., is specialized in Special Gas Compressor. We warmly welcome your small trial order for quality or market test.
Q2: Are you a manufacturer or trading company?
A: We are professional manufacturer with big modern factory in Anhui, China. Both OEM & ODM service can be accepted.
Q3: What's your delivery time?
A: Generally 30 to 60 days, if urgently order, please contact our sales in advance.
Q4: How long is your air compressor warranty?
A: One year for the whole machine and two years for screw air end, except spare parts.
Q5: How long could your air compressor be used?
A: Generally, more than 15 years.
Q6: What's payment term?
A: T/T, L/C, Western Union, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.
Q7: How about your customer service?
A: 24 hours online service available. 48hours problem solved promise.
Q8: How about your after-sales service?
A: Installation Services and online instructions. Well-trained engineers available to overseas service.
A: Installation Services and online instructions. Well-trained engineers available to overseas service.
